Implements the gradient_t type.

Data Types
type	gradient_t
	A simulation component that computes the gradient of a field. Wraps the `gradient` operator. More...

Functions/Subroutines
subroutine	gradient_init_from_json (this, json, case)
	Constructor from json.

subroutine	gradient_init_common (this, field_name, computed_field)
	Common part of the constructors.

subroutine	gradient_init_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller, field_name, computed_field, filename, precision)
	Constructor from components, passing controllers.

subroutine	gradient_init_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, field_name, computed_field, filename, precision)
	Constructor from components, passing properties to the time_based_controller` components in the base type.

subroutine	gradient_free (this)
	Destructor.

subroutine	gradient_compute (this, time)
	Compute the gradient field.

Function/Subroutine Documentation

◆ gradient_compute()

subroutine gradient_simcomp::gradient_compute	(	class(gradient_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

private

Parameters

time	The current time value

Definition at line 236 of file gradient_simcomp.f90.

Here is the call graph for this function:

subroutine gradient_simcomp::gradient_free ( class(gradient_t), intent(inout) this )

private

Definition at line 224 of file gradient_simcomp.f90.

subroutine gradient_simcomp::gradient_init_common	(	class(gradient_t), intent(inout)	this,
		character(len=*)	field_name,
		character(len=*)	computed_field
	)

private

Definition at line 117 of file gradient_simcomp.f90.

subroutine gradient_simcomp::gradient_init_from_controllers	(	class(gradient_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*)	field_name,
		character(len=*)	computed_field,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

private

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
field_name	The name of the field to compute the gradient of.
computed_field	The base name of the gradient field components.
filename	The name of the file save the fields to. Optional, if not
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 145 of file gradient_simcomp.f90.

subroutine gradient_simcomp::gradient_init_from_controllers_properties	(	class(gradient_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*)	field_name,
		character(len=*)	computed_field,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

private

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
field_name	The name of the field to compute the gradient of.
computed_field	The base name of the gradient field components.
filename	The name of the file save the fields to. Optional, if not provided, fields are added to the main output file.
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 189 of file gradient_simcomp.f90.

subroutine gradient_simcomp::gradient_init_from_json	(	class(gradient_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

Definition at line 88 of file gradient_simcomp.f90.
