Explicit wall model based on Model-II from Cai and Sagaut (2021). More...

Inheritance diagram for cai_sagaut_model_ii::cai_sagaut_model_ii_t:

Collaboration diagram for cai_sagaut_model_ii::cai_sagaut_model_ii_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, scheme_name, coef, msk, facet, h_index, json)
	Initialise the wall model from the case file.

procedure, pass(this)	partial_init (this, coef, json)
	Partially initialise the wall model from the case file.

procedure, pass(this)	finalize (this, msk, facet)
	Finalise allocation of derived data structures.

procedure, pass(this)	init_from_components (this, scheme_name, coef, msk, facet, h_index, kappa, b, p, s)
	Initialise the wall model from explicit components.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	compute_nu_and_rho (this)
	Compute wall-node viscosity and density samples.

procedure, pass(this)	compute (this, t, tstep)
	Evaluate wall shear stresses.

procedure, pass(this)	init_base (this, scheme_name, coef, msk, facet, index)
	Constructor for the wall_model_t (base) class.

procedure, pass(this)	partial_init_base (this, coef, json)
	Base type implementation of the deferred `partial_init`.

procedure, pass(this)	finalize_base (this, msk, facet)
	Base type implementation of the deferred `finilize`.

procedure, pass(this)	free_base (this)
	Destructor for the wall_model_t (base) class.

procedure, pass(this)	compute_mag_field (this)
	Compute the wall shear stress's magnitude.

procedure(wall_model_init), deferred, pass	init (this, scheme_name, coef, msk, facet, h_index, json)
	The common constructor.

procedure(wall_model_partial_init), deferred, pass	partial_init (this, coef, json)
	A part of the constructor that parses the JSON without initializing the base `wall_model_t` type. Used in `wall_model_bc_t` during the init stage of the bc construction. So, in this routine you cannot use the bc mask and facets. The construction can be finished by calling `finalize_base`. This generally follows the same pattern as in `bc_t`. This constructor gets the scheme_name from the JSON. This is currently hacked in by the `pnpn_bc_factory`.

procedure(wall_model_finalize), deferred, pass	finalize (this, msk, facet)
	Finalization of the partial construction, similar to `bc_t`.

procedure(wall_model_free), deferred, pass	free (this)
	Destructor.

procedure(wall_model_compute), deferred, pass	compute (this, t, tstep)
	Compute the wall shear stress.

procedure, pass(this)	find_points (this)
	Find the sampling points based on the value of `h_index`.

Public Attributes
real(kind=rp)	kappa = 0.41_rp
	The von Karman coefficient.

real(kind=rp)	b = 5.2_rp
	The log-law intercept.

real(kind=rp)	p = 1.138_rp
	Blending exponent.

real(kind=rp)	s = 217.8_rp
	Blending scale.

type(vector_t)	nu
	The kinematic viscosity.

type(vector_t)	rho_w
	The fluid density at the boundary.

type(coef_t), pointer	coef => null()
	SEM coefficients.

type(dofmap_t), pointer	dof => null()
	Map of degrees of freedom.

type(field_t), pointer	mu => null()
	The dynamic viscosity of the fluid.

type(field_t), pointer	rho => null()
	The density of the fluid.

character(len=:), allocatable	scheme_name
	The name of the scheme for which the wall model is used. This is used to identify the name of the mu an rho fields in the registry.

integer, dimension(:), pointer	msk => null()
	The boundary condition mask. Stores the array size at index zero!

type(c_ptr)	msk_d = C_NULL_PTR

integer, dimension(:), pointer	facet => null()
	The boundary condition facet ids. Stores the array size at index zero!

type(vector_t)	tau_x
	The x component of the shear stress.

type(vector_t)	tau_y
	The y component of the shear stress.

type(vector_t)	tau_z
	The z component of the shear stress.

type(vector_t)	n_x
	The x component of the normal.

type(vector_t)	n_y
	The y component of the normal.

type(vector_t)	n_z
	The z component of the normal.

integer, dimension(:), allocatable	ind_r
	The r indices of the sampling points.

type(c_ptr)	ind_r_d = C_NULL_PTR

integer, dimension(:), allocatable	ind_s
	The s indices of the sampling points.

type(c_ptr)	ind_s_d = C_NULL_PTR

integer, dimension(:), allocatable	ind_t
	The t indices of the sampling points.

type(c_ptr)	ind_t_d = C_NULL_PTR

integer, dimension(:), allocatable	ind_e
	The element indices of the sampling points.

type(c_ptr)	ind_e_d = C_NULL_PTR

type(vector_t)	h
	The sampling height.

integer	h_index = 0
	Sampling index.

integer	n_nodes = 0
	Number of nodes in the boundary.

type(field_t), pointer	tau_field => null()
	The 3D field with the computed stress magnitude at the boundary.

Detailed Description

Reference: https://doi.org/10.1063/5.0048563

Definition at line 56 of file cai_sagaut_model_ii.f90.

Member Function/Subroutine Documentation

◆ compute() [1/2]

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::compute	(	class(cai_sagaut_model_ii_t), intent(inout)	this,
		real(kind=rp), intent(in)	t,
		integer, intent(in)	tstep
	)

Parameters

t	The current physical time.
tstep	The current time-step number.

Definition at line 85 of file cai_sagaut_model_ii.f90.

◆ compute() [2/2]

procedure(wall_model_compute), deferred, pass wall_model::wall_model_t::compute	(	class(wall_model_t), intent(inout)	this,
		real(kind=rp), intent(in)	t,
		integer, intent(in)	tstep
	)

pure virtualinherited

Definition at line 134 of file wall_model.f90.

◆ compute_mag_field()

procedure, pass(this) wall_model::wall_model_t::compute_mag_field ( class(wall_model_t), intent(inout) this )

inherited

Definition at line 118 of file wall_model.f90.

◆ compute_nu_and_rho()

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::compute_nu_and_rho ( class(cai_sagaut_model_ii_t), intent(inout) this )

Definition at line 82 of file cai_sagaut_model_ii.f90.

◆ finalize() [1/2]

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::finalize	(	class(cai_sagaut_model_ii_t), intent(inout)	this,
		integer, dimension(:), intent(in)	msk,
		integer, dimension(:), intent(in)	facet
	)

Parameters

msk	The wall-point mask.
facet	The wall-point facet indices.

Definition at line 75 of file cai_sagaut_model_ii.f90.

◆ finalize() [2/2]

procedure(wall_model_finalize), deferred, pass wall_model::wall_model_t::finalize	(	class(wall_model_t), intent(inout)	this,
		integer, dimension(:), intent(in)	msk,
		integer, dimension(:), intent(in)	facet
	)

pure virtualinherited

Definition at line 130 of file wall_model.f90.

◆ finalize_base()

procedure, pass(this) wall_model::wall_model_t::finalize_base	(	class(wall_model_t), intent(inout)	this,
		integer, dimension(0:), intent(in), target	msk,
		integer, dimension(:), intent(in), target	facet
	)

inherited

Definition at line 114 of file wall_model.f90.

◆ find_points()

procedure, pass(this) wall_model::wall_model_t::find_points ( class(wall_model_t), intent(inout) this )

inherited

Definition at line 136 of file wall_model.f90.

◆ free() [1/2]

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::free ( class(cai_sagaut_model_ii_t), intent(inout) this )

Definition at line 80 of file cai_sagaut_model_ii.f90.

◆ free() [2/2]

procedure(wall_model_free), deferred, pass wall_model::wall_model_t::free ( class(wall_model_t), intent(inout) this )

pure virtualinherited

Definition at line 132 of file wall_model.f90.

◆ free_base()

procedure, pass(this) wall_model::wall_model_t::free_base ( class(wall_model_t), intent(inout) this )

inherited

Definition at line 116 of file wall_model.f90.

◆ init() [1/2]

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::init	(	class(cai_sagaut_model_ii_t), intent(inout)	this,
		character(len=*), intent(in)	scheme_name,
		type(coef_t), intent(in)	coef,
		integer, dimension(:), intent(in)	msk,
		integer, dimension(:), intent(in)	facet,
		integer, intent(in)	h_index,
		type(json_file), intent(inout)	json
	)

Parameters

scheme_name	The solver scheme name.
coef	The SEM coefficients.
msk	The wall-point mask.
facet	The wall-point facet indices.
h_index	The GLL index used for wall-model sampling.
json	The case-file parameters for this wall model.

Definition at line 71 of file cai_sagaut_model_ii.f90.

◆ init() [2/2]

procedure(wall_model_init), deferred, pass wall_model::wall_model_t::init	(	class(wall_model_t), intent(inout)	this,
		character(len=*), intent(in)	scheme_name,
		type(coef_t), intent(in)	coef,
		integer, dimension(:), intent(in)	msk,
		integer, dimension(:), intent(in)	facet,
		integer, intent(in)	h_index,
		type(json_file), intent(inout)	json
	)

pure virtualinherited

Definition at line 120 of file wall_model.f90.

◆ init_base()

procedure, pass(this) wall_model::wall_model_t::init_base	(	class(wall_model_t), intent(inout)	this,
		character(len=*)	scheme_name,
		type(coef_t), intent(in), target	coef,
		integer, dimension(0:), intent(in), target	msk,
		integer, dimension(0:), intent(in), target	facet,
		integer, intent(in)	index
	)

inherited

Parameters

coef	SEM coefficients.
msk	The underlying mask of the boundary condition.
facet,The	underlying facet index list of the boundary condition.
scheme_name	The name of the scheme for which the wall model is used.
index	The off-wall index of the sampling point.

Definition at line 110 of file wall_model.f90.

◆ init_from_components()

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::init_from_components	(	class(cai_sagaut_model_ii_t), intent(inout)	this,
		character(len=*), intent(in)	scheme_name,
		type(coef_t), intent(in)	coef,
		integer, dimension(:), intent(in)	msk,
		integer, dimension(:), intent(in)	facet,
		integer, intent(in)	h_index,
		real(kind=rp), intent(in)	kappa,
		real(kind=rp), intent(in)	b,
		real(kind=rp), intent(in)	p,
		real(kind=rp), intent(in)	s
	)

Parameters

scheme_name	The solver scheme name.
coef	The SEM coefficients.
msk	The wall-point mask.
facet	The wall-point facet indices.
h_index	The GLL index used for wall-model sampling.
kappa	The von Karman coefficient.
B	The log-law intercept.
p	The blending exponent.
s	The blending scale.

Definition at line 77 of file cai_sagaut_model_ii.f90.

◆ partial_init() [1/2]

procedure, pass(this) cai_sagaut_model_ii::cai_sagaut_model_ii_t::partial_init	(	class(cai_sagaut_model_ii_t), intent(inout)	this,
		type(coef_t), intent(in)	coef,
		type(json_file), intent(inout)	json
	)

Parameters

coef	The SEM coefficients.
json	The case-file parameters for this wall model.

Definition at line 73 of file cai_sagaut_model_ii.f90.

◆ partial_init() [2/2]

procedure(wall_model_partial_init), deferred, pass wall_model::wall_model_t::partial_init	(	class(wall_model_t), intent(inout)	this,
		type(coef_t), intent(in)	coef,
		type(json_file), intent(inout)	json
	)

pure virtualinherited

Definition at line 128 of file wall_model.f90.

◆ partial_init_base()

procedure, pass(this) wall_model::wall_model_t::partial_init_base	(	class(wall_model_t), intent(inout)	this,
		type(coef_t), intent(in), target	coef,
		type(json_file), intent(inout)	json
	)

inherited

Parameters

coef	SEM coefficients.
The	name of the scheme for which the wall model is used.
json	A dictionary with parameters.

Definition at line 112 of file wall_model.f90.

Member Data Documentation

◆ b

real(kind=rp) cai_sagaut_model_ii::cai_sagaut_model_ii_t::b = 5.2_rp

Definition at line 60 of file cai_sagaut_model_ii.f90.

◆ coef

type(coef_t), pointer wall_model::wall_model_t::coef => null()

inherited

Definition at line 60 of file wall_model.f90.

◆ dof

type(dofmap_t), pointer wall_model::wall_model_t::dof => null()

inherited

Definition at line 62 of file wall_model.f90.

◆ facet

integer, dimension(:), pointer wall_model::wall_model_t::facet => null()

inherited

Definition at line 75 of file wall_model.f90.

◆ h

type(vector_t) wall_model::wall_model_t::h

inherited

Definition at line 101 of file wall_model.f90.

◆ h_index

integer wall_model::wall_model_t::h_index = 0

inherited

Definition at line 103 of file wall_model.f90.

◆ ind_e

integer, dimension(:), allocatable wall_model::wall_model_t::ind_e

inherited

Definition at line 98 of file wall_model.f90.

◆ ind_e_d

type(c_ptr) wall_model::wall_model_t::ind_e_d = C_NULL_PTR

inherited

Definition at line 99 of file wall_model.f90.

◆ ind_r

integer, dimension(:), allocatable wall_model::wall_model_t::ind_r

inherited

Definition at line 89 of file wall_model.f90.

◆ ind_r_d

type(c_ptr) wall_model::wall_model_t::ind_r_d = C_NULL_PTR

inherited

Definition at line 90 of file wall_model.f90.

◆ ind_s

integer, dimension(:), allocatable wall_model::wall_model_t::ind_s

inherited

Definition at line 92 of file wall_model.f90.

◆ ind_s_d

type(c_ptr) wall_model::wall_model_t::ind_s_d = C_NULL_PTR

inherited

Definition at line 93 of file wall_model.f90.

◆ ind_t

integer, dimension(:), allocatable wall_model::wall_model_t::ind_t

inherited

Definition at line 95 of file wall_model.f90.

◆ ind_t_d

type(c_ptr) wall_model::wall_model_t::ind_t_d = C_NULL_PTR

inherited

Definition at line 96 of file wall_model.f90.

◆ kappa

real(kind=rp) cai_sagaut_model_ii::cai_sagaut_model_ii_t::kappa = 0.41_rp

Definition at line 58 of file cai_sagaut_model_ii.f90.

◆ msk

integer, dimension(:), pointer wall_model::wall_model_t::msk => null()

inherited

Definition at line 72 of file wall_model.f90.

◆ msk_d

type(c_ptr) wall_model::wall_model_t::msk_d = C_NULL_PTR

inherited

Definition at line 73 of file wall_model.f90.

◆ mu

type(field_t), pointer wall_model::wall_model_t::mu => null()

inherited

Definition at line 64 of file wall_model.f90.

◆ n_nodes

integer wall_model::wall_model_t::n_nodes = 0

inherited

Definition at line 105 of file wall_model.f90.

◆ n_x

type(vector_t) wall_model::wall_model_t::n_x

inherited

Definition at line 83 of file wall_model.f90.

◆ n_y

type(vector_t) wall_model::wall_model_t::n_y

inherited

Definition at line 85 of file wall_model.f90.

◆ n_z

type(vector_t) wall_model::wall_model_t::n_z

inherited

Definition at line 87 of file wall_model.f90.

◆ nu

type(vector_t) cai_sagaut_model_ii::cai_sagaut_model_ii_t::nu

Definition at line 66 of file cai_sagaut_model_ii.f90.

◆ p

real(kind=rp) cai_sagaut_model_ii::cai_sagaut_model_ii_t::p = 1.138_rp

Definition at line 62 of file cai_sagaut_model_ii.f90.

◆ rho

type(field_t), pointer wall_model::wall_model_t::rho => null()

inherited

Definition at line 66 of file wall_model.f90.

◆ rho_w

type(vector_t) cai_sagaut_model_ii::cai_sagaut_model_ii_t::rho_w

Definition at line 68 of file cai_sagaut_model_ii.f90.

◆ s

real(kind=rp) cai_sagaut_model_ii::cai_sagaut_model_ii_t::s = 217.8_rp

Definition at line 64 of file cai_sagaut_model_ii.f90.

◆ scheme_name

character(len=:), allocatable wall_model::wall_model_t::scheme_name

inherited

Definition at line 70 of file wall_model.f90.

◆ tau_field

type(field_t), pointer wall_model::wall_model_t::tau_field => null()

inherited

Definition at line 107 of file wall_model.f90.

◆ tau_x

type(vector_t) wall_model::wall_model_t::tau_x

inherited

Definition at line 77 of file wall_model.f90.

◆ tau_y

type(vector_t) wall_model::wall_model_t::tau_y

inherited

Definition at line 79 of file wall_model.f90.

◆ tau_z

type(vector_t) wall_model::wall_model_t::tau_z

inherited

Definition at line 81 of file wall_model.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/wall_models/cai_sagaut_model_ii.f90

Public Member Functions

Public Attributes

Detailed Description

Member Function/Subroutine Documentation

◆ compute() [1/2]

◆ compute() [2/2]

◆ compute_mag_field()

◆ compute_nu_and_rho()

◆ finalize() [1/2]

◆ finalize() [2/2]

◆ finalize_base()

◆ find_points()

◆ free() [1/2]

◆ free() [2/2]

◆ free_base()

◆ init() [1/2]

◆ init() [2/2]

◆ init_base()

◆ init_from_components()

◆ partial_init() [1/2]

◆ partial_init() [2/2]

◆ partial_init_base()

Member Data Documentation

◆ b

◆ coef

◆ dof

◆ facet

◆ h

◆ h_index

◆ ind_e

◆ ind_e_d

◆ ind_r

◆ ind_r_d

◆ ind_s

◆ ind_s_d

◆ ind_t

◆ ind_t_d

◆ kappa

◆ msk

◆ msk_d

◆ mu

◆ n_nodes

◆ n_x

◆ n_y

◆ n_z

◆ nu

◆ p

◆ rho

◆ rho_w

◆ s

◆ scheme_name

◆ tau_field

◆ tau_x

◆ tau_y

◆ tau_z
