Inheritance diagram for fluid_sgs_stats::fluid_sgs_stats_t:

Collaboration diagram for fluid_sgs_stats::fluid_sgs_stats_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, coef, u, v, w, nut_field)
	Constructor.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	update (this, k)
	Update all the mean value fields with a new sample.

procedure, pass(this)	reset (this)
	Reset all the computed means values and sampling times to zero.

procedure(stats_quant_update), deferred, pass	update (this, k)

Public Attributes
type(field_t)	stats_work
	Work fields.

type(field_t), pointer	s11_work

type(field_t), pointer	s22_work

type(field_t), pointer	s33_work

type(field_t), pointer	s12_work

type(field_t), pointer	s13_work

type(field_t), pointer	s23_work

type(field_t), pointer	nut
	Pointers to the instantenious quantities.

type(field_t), pointer	u
	u

type(field_t), pointer	v
	v

type(field_t), pointer	w
	w

type(mean_field_t)	nut_mean
	<nut>

type(mean_field_t)	uu_sgs
	<uu_sgs> = <2nut*S11>

type(mean_field_t)	vv_sgs
	<vv_sgs> = <2nut*S22>

type(mean_field_t)	ww_sgs
	<ww_sgs> = <2nut*S33>

type(mean_field_t)	uv_sgs
	<uv_sgs> = <2nut*S12>

type(mean_field_t)	uw_sgs
	<uw_sgs> = <2nut*S13>

type(mean_field_t)	vw_sgs
	<vw_sgs> = <2nut*S23>

type(coef_t), pointer	coef
	SEM coefficients.

integer	n_stats = 7
	Number of statistical fields to be computed.

type(field_list_t)	stat_fields
	A list of size n_stats, whith entries pointing to the fields that will be output (the field components above.) Used to write the output.

Detailed Description

Definition at line 49 of file fluid_sgs_stats.f90.

Member Function/Subroutine Documentation

◆ free()

procedure, pass(this) fluid_sgs_stats::fluid_sgs_stats_t::free ( class(fluid_sgs_stats_t), intent(inout) this )

Definition at line 87 of file fluid_sgs_stats.f90.

◆ init()

procedure, pass(this) fluid_sgs_stats::fluid_sgs_stats_t::init	(	class(fluid_sgs_stats_t), intent(inout), target	this,
		type(coef_t), target	coef,
		type(field_t), intent(in), target	u,
		type(field_t), intent(in), target	v,
		type(field_t), intent(in), target	w,
		character(*), intent(in), optional	nut_field
	)

Parameters

coef	SEM coefficients.
u	The x component of velocity.
v	The y component of velocity.
w	The z component of velocity.
nut_field	Specifies the name of the nut field. Optional, defaults to `nut`.

Definition at line 85 of file fluid_sgs_stats.f90.

◆ reset()

procedure, pass(this) fluid_sgs_stats::fluid_sgs_stats_t::reset ( class(fluid_sgs_stats_t), intent(inout), target this )

Definition at line 91 of file fluid_sgs_stats.f90.

◆ update() [1/2]

procedure(stats_quant_update), deferred, pass stats_quant::stats_quant_t::update	(	class(stats_quant_t), intent(inout)	this,
		real(kind=rp), intent(in)	k
	)

pure virtualinherited

Definition at line 42 of file stats_quant.f90.

◆ update() [2/2]

procedure, pass(this) fluid_sgs_stats::fluid_sgs_stats_t::update	(	class(fluid_sgs_stats_t), intent(inout)	this,
		real(kind=rp), intent(in)	k
	)

Parameters

k	Time elapsed since the last update.

Definition at line 89 of file fluid_sgs_stats.f90.

Member Data Documentation

◆ coef

type(coef_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::coef

Definition at line 75 of file fluid_sgs_stats.f90.

◆ n_stats

integer fluid_sgs_stats::fluid_sgs_stats_t::n_stats = 7

Definition at line 78 of file fluid_sgs_stats.f90.

◆ nut

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::nut

nut

Definition at line 60 of file fluid_sgs_stats.f90.

◆ nut_mean

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::nut_mean

Definition at line 65 of file fluid_sgs_stats.f90.

◆ s11_work

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::s11_work

Definition at line 52 of file fluid_sgs_stats.f90.

◆ s12_work

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::s12_work

Definition at line 55 of file fluid_sgs_stats.f90.

◆ s13_work

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::s13_work

Definition at line 56 of file fluid_sgs_stats.f90.

◆ s22_work

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::s22_work

Definition at line 53 of file fluid_sgs_stats.f90.

◆ s23_work

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::s23_work

Definition at line 57 of file fluid_sgs_stats.f90.

◆ s33_work

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::s33_work

Definition at line 54 of file fluid_sgs_stats.f90.

◆ stat_fields

type(field_list_t) fluid_sgs_stats::fluid_sgs_stats_t::stat_fields

Definition at line 82 of file fluid_sgs_stats.f90.

◆ stats_work

type(field_t) fluid_sgs_stats::fluid_sgs_stats_t::stats_work

Definition at line 51 of file fluid_sgs_stats.f90.

◆ u

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::u

Definition at line 61 of file fluid_sgs_stats.f90.

◆ uu_sgs

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::uu_sgs

Definition at line 67 of file fluid_sgs_stats.f90.

◆ uv_sgs

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::uv_sgs

Definition at line 70 of file fluid_sgs_stats.f90.

◆ uw_sgs

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::uw_sgs

Definition at line 71 of file fluid_sgs_stats.f90.

◆ v

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::v

Definition at line 62 of file fluid_sgs_stats.f90.

◆ vv_sgs

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::vv_sgs

Definition at line 68 of file fluid_sgs_stats.f90.

◆ vw_sgs

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::vw_sgs

Definition at line 72 of file fluid_sgs_stats.f90.

◆ w

type(field_t), pointer fluid_sgs_stats::fluid_sgs_stats_t::w

Definition at line 63 of file fluid_sgs_stats.f90.

◆ ww_sgs

type(mean_field_t) fluid_sgs_stats::fluid_sgs_stats_t::ww_sgs

Definition at line 69 of file fluid_sgs_stats.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/les/fluid_sgs_stats.f90
