vtkhdf_file Module Reference

VTKHDF file format.

Data Types
type	vtkhdf_file_t
	Interface for HDF5 files. More...

Functions/Subroutines
subroutine	vtkhdf_file_set_overwrite (this, overwrite)
	Set the overwrite flag for HDF5 files.
subroutine	vtkhdf_file_enable_amr (this)
	Enable support for Adaptive Mesh Refinement.
subroutine	vtkhdf_file_set_precision (this, precision)
	Set the precision for VTKHDF output (single or double)
character(len=1024) function	vtkhdf_file_get_fname (this)
	Return the file name with the start counter.
subroutine	vtkhdf_file_set_subdivide (this, subdivide)
	Enable or disable subdivision of spectral elements into linear sub-cells. When subdivision is enabled, each spectral element is written as multiple linear VTK cells (VTK_HEXAHEDRON in 3D, VTK_QUAD in 2D) with connectivity corresponding to the tensor-product grid of the spectral element.
subroutine	vtkhdf_file_write (this, data, t)
	Write data in HDF5 format (no HDF5 support)
subroutine	vtkhdf_file_read (this, data)
	Read data in HDF5 format (no HDF5 support)
pure integer function, dimension(8 *(lx - 1) *(ly - 1) *(lz - 1))	subdivide_to_hex_ordering (lx, ly, lz)
	Build linear hexahedron sub-cell node ordering for a spectral element. Returns an array of 0-based tensor-product indices that subdivides the lx*ly*lz grid into (lx-1)*(ly-1)*(lz-1) linear hexahedra (VTK_HEXAHEDRON, type 12), with 8 nodes per sub-cell.
pure integer function, dimension(4 *(lx - 1) *(ly - 1))	subdivide_to_quad_ordering (lx, ly)
	Build linear quadrilateral sub-cell node ordering for a spectral element. Returns an array of 0-based tensor-product indices that subdivides the lx*ly grid into (lx-1)*(ly-1) linear quadrilaterals (VTK_QUAD, type 9), with 4 nodes per sub-cell.

Variables
integer, dimension(2), parameter	vtkhdf_version = [2, 6]

Function/Subroutine Documentation

subdivide_to_hex_ordering()

pure integer function, dimension(8 * (lx - 1) * (ly - 1) * (lz - 1)) vtkhdf_file::subdivide_to_hex_ordering ( integer, intent(in)  lx, integer, intent(in)  ly, integer, intent(in)  lz  )

private

Parameters

lx	Number of points in x-direction
ly	Number of points in y-direction
lz	Number of points in z-direction

Returns

Array of size 8*(lx-1)*(ly-1)*(lz-1) with 0-based indices

Definition at line 1466 of file vtkhdf_file.F90.

Here is the caller graph for this function:

subdivide_to_quad_ordering()

pure integer function, dimension(4 * (lx - 1) * (ly - 1)) vtkhdf_file::subdivide_to_quad_ordering ( integer, intent(in)  lx, integer, intent(in)  ly  )

private

Parameters

lx	Number of points in x-direction
ly	Number of points in y-direction

Returns

Array of size 4*(lx-1)*(ly-1) with 0-based indices

Definition at line 1498 of file vtkhdf_file.F90.

Here is the caller graph for this function:

vtkhdf_file_enable_amr()

subroutine vtkhdf_file::vtkhdf_file_enable_amr ( class(vtkhdf_file_t), intent(inout)  this )

private

Definition at line 106 of file vtkhdf_file.F90.

vtkhdf_file_get_fname()

character(len=1024) function vtkhdf_file::vtkhdf_file_get_fname ( class(vtkhdf_file_t), intent(in)  this )

private

Definition at line 119 of file vtkhdf_file.F90.

Here is the call graph for this function:

vtkhdf_file_read()

subroutine vtkhdf_file::vtkhdf_file_read ( class(vtkhdf_file_t)  this, class(*), intent(inout), target  data  )

private

Definition at line 1447 of file vtkhdf_file.F90.

vtkhdf_file_set_overwrite()

subroutine vtkhdf_file::vtkhdf_file_set_overwrite ( class(vtkhdf_file_t), intent(inout)  this, logical, intent(in)  overwrite  )

private

Definition at line 99 of file vtkhdf_file.F90.

vtkhdf_file_set_precision()

subroutine vtkhdf_file::vtkhdf_file_set_precision ( class(vtkhdf_file_t), intent(inout)  this, integer, intent(in)  precision  )

private

Definition at line 112 of file vtkhdf_file.F90.

vtkhdf_file_set_subdivide()

subroutine vtkhdf_file::vtkhdf_file_set_subdivide ( class(vtkhdf_file_t), intent(inout)  this, logical, intent(in)  subdivide  )

private

Parameters

subdivide

Whether to subdivide into linear sub-cells.

Definition at line 138 of file vtkhdf_file.F90.

Here is the call graph for this function:

vtkhdf_file_write()

subroutine vtkhdf_file::vtkhdf_file_write ( class(vtkhdf_file_t), intent(inout)  this, class(*), intent(in), target  data, real(kind=rp), intent(in), optional  t  )

private

Definition at line 1439 of file vtkhdf_file.F90.

Variable Documentation

vtkhdf_version

integer, dimension(2), parameter vtkhdf_file::vtkhdf_version = [2, 6]

Definition at line 91 of file vtkhdf_file.F90.
