hpfrt_source_term::hpfrt_source_term_t Type Reference

High-pass filter relaxation source term. More...

Inheritance diagram for hpfrt_source_term::hpfrt_source_term_t:

Collaboration diagram for hpfrt_source_term::hpfrt_source_term_t:

Public Member Functions
procedure, pass(this)	init (this, json, fields, coef, variable_name)
	The common constructor using a JSON object.
procedure, pass(this)	init_from_components (this, fields, coef, filter_weight, filter_modes, start_time, end_time, field_name)
	The constructor from type components.
procedure, pass(this)	free (this)
	Destructor.
procedure, pass(this)	compute_ (this, time)
	Computes the source term and adds the result to fields.
procedure, pass(this)	init_base (this, fields, coef, start_time, end_time)
	Constructor for the source_term_t (base) type.
procedure, pass(this)	free_base (this)
	Destructor for the source_term_t (base) type.
procedure, pass(this)	compute (this, time)
	Executes compute_ based on time conditions.
procedure(source_term_init), deferred, pass	init (this, json, fields, coef, variable_name)
	The common constructor using a JSON object.
procedure(source_term_free), deferred, pass	free (this)
	Destructor.
procedure(source_term_compute), deferred, pass	compute_ (this, time)
	Computes the source term and adds the result to fields.

Public Attributes
integer	filter_modes = 0
	Number of high modes affected by the filter.
real(kind=rp)	chi = 0.0_rp
	Damping coefficient, stored as a non-positive value.
type(elementwise_filter_t)	filter
	Low-pass elementwise filter.
type(field_list_t)	source_fields
	Fields to filter before adding to the source RHS.
type(field_list_t)	fields
	The fields to be updated with the source term values.
type(coef_t), pointer	coef => null()
	Coefficients for the SEM.
real(kind=rp)	start_time = 0.0_rp
	Start time for adding the source term.
real(kind=rp)	end_time = huge(0.0_rp)
	End time for adding the source term.

Detailed Description

The low-pass filter is built from a one-dimensional modal transfer function. For filter_modes = \(k_f\) and \(n = lx\), let \(k_0 = n - k_f\). The modal transfer function is

\[ \sigma_k = \begin{cases} 1, & k \leq k_0,\\ 1 - \left(\frac{k-k_0}{k_f}\right)^2, & k_0 < k \leq n. \end{cases} \]

The source term adds \(\chi (I - F)\phi\), where \(\chi = -|\texttt{filter_weight}|\).

Definition at line 65 of file hpfrt_source_term.f90.

Member Function/Subroutine Documentation

compute()

procedure, pass(this) source_term::source_term_t::compute ( class(source_term_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	Time state.

Definition at line 59 of file source_term.f90.

compute_() [1/2]

procedure, pass(this) hpfrt_source_term::hpfrt_source_term_t::compute_	(	class(hpfrt_source_term_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

time	The time state.

Definition at line 83 of file hpfrt_source_term.f90.

compute_() [2/2]

procedure(source_term_compute), deferred, pass source_term::source_term_t::compute_ ( class(source_term_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

pure virtualinherited

Definition at line 65 of file source_term.f90.

free() [1/2]

procedure, pass(this) hpfrt_source_term::hpfrt_source_term_t::free

(

class(hpfrt_source_term_t), intent(inout)

this

)

Definition at line 81 of file hpfrt_source_term.f90.

free() [2/2]

procedure(source_term_free), deferred, pass source_term::source_term_t::free ( class(source_term_t), intent(inout)  this )

pure virtualinherited

Definition at line 63 of file source_term.f90.

free_base()

procedure, pass(this) source_term::source_term_t::free_base ( class(source_term_t), intent(inout)  this )

inherited

Definition at line 57 of file source_term.f90.

init() [1/2]

procedure, pass(this) hpfrt_source_term::hpfrt_source_term_t::init	(	class(hpfrt_source_term_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		character(len=*), intent(in)	variable_name
	)

Parameters

json	The JSON object for the source.
fields	A list of fields for adding the source values.
coef	The SEM coeffs.
variable_name	The name of the variable where the source term acts.

Definition at line 76 of file hpfrt_source_term.f90.

init() [2/2]

procedure(source_term_init), deferred, pass source_term::source_term_t::init ( class(source_term_t), intent(inout)  this, type(json_file), intent(inout)  json, type(field_list_t), intent(in), target  fields, type(coef_t), intent(in), target  coef, character(len=*), intent(in)  variable_name  )

pure virtualinherited

Definition at line 61 of file source_term.f90.

init_base()

procedure, pass(this) source_term::source_term_t::init_base ( class(source_term_t), intent(inout)  this, type(field_list_t)  fields, type(coef_t), intent(in), target  coef, real(kind=rp), intent(in)  start_time, real(kind=rp), intent(in)  end_time  )

inherited

Parameters

fields	A list of pointers to fields to be updated by the source term.
coef	SEM coefs.
start_time	When to start adding the source term.
end_time	When to stop adding the source term.

Definition at line 55 of file source_term.f90.

init_from_components()

procedure, pass(this) hpfrt_source_term::hpfrt_source_term_t::init_from_components	(	class(hpfrt_source_term_t), intent(inout)	this,
		class(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), intent(in)	filter_weight,
		integer, intent(in)	filter_modes,
		real(kind=rp), intent(in)	start_time,
		real(kind=rp), intent(in)	end_time,
		character(len=*), intent(in)	field_name
	)

Parameters

fields	A list of fields for adding the source values.
coef	The SEM coeffs.
filter_weight	The positive damping coefficient magnitude.
filter_modes	Number of high modes affected by the filter.
start_time	When to start adding the source term.
end_time	When to stop adding the source term.
field_name	Name of the scalar field for scalar source terms.

Definition at line 78 of file hpfrt_source_term.f90.

Member Data Documentation

chi

real(kind=rp) hpfrt_source_term::hpfrt_source_term_t::chi = 0.0_rp

Definition at line 69 of file hpfrt_source_term.f90.

coef

type(coef_t), pointer source_term::source_term_t::coef => null()

inherited

Definition at line 48 of file source_term.f90.

end_time

real(kind=rp) source_term::source_term_t::end_time = huge(0.0_rp)

inherited

Definition at line 52 of file source_term.f90.

fields

type(field_list_t) source_term::source_term_t::fields

inherited

Definition at line 46 of file source_term.f90.

filter

type(elementwise_filter_t) hpfrt_source_term::hpfrt_source_term_t::filter

Definition at line 71 of file hpfrt_source_term.f90.

filter_modes

integer hpfrt_source_term::hpfrt_source_term_t::filter_modes = 0

Definition at line 67 of file hpfrt_source_term.f90.

source_fields

type(field_list_t) hpfrt_source_term::hpfrt_source_term_t::source_fields

Definition at line 73 of file hpfrt_source_term.f90.

start_time

real(kind=rp) source_term::source_term_t::start_time = 0.0_rp

inherited

Definition at line 50 of file source_term.f90.

---

The documentation for this type was generated from the following file:

• /home/runner/work/neko/neko/src/source_terms/hpfrt_source_term.f90
