artificial_viscosity_model::avm_t Type Reference

Base abstract type for artificial viscosity models. More...

Inheritance diagram for artificial_viscosity_model::avm_t:

Collaboration diagram for artificial_viscosity_model::avm_t:

Public Member Functions
procedure, pass(this)	init_base (this, dof, coef, reg_coeff_name)
	Constructor for the avm_t (base) class.
procedure, pass(this)	free_base (this)
	Destructor for the avm_t (base) class.
procedure(avm_init), deferred, pass	init (this, case, json)
	The common constructor.
procedure(avm_free), deferred, pass	free (this)
	Destructor.
procedure(avm_preprocess), deferred, pass	preprocess (this, time)
	Perform artificial viscosity related computations before the time step.
procedure(avm_compute), deferred, pass	compute (this, time)
	Perform artificial viscosity related computations after the time step.
procedure, pass(this)	restart (this, time)
	Restore model state after loading a checkpoint.

Public Attributes
type(field_t), pointer	reg_coeff => null()
	Artificial viscosity.
type(coef_t), pointer	coef => null()
	SEM coefficients.
type(dofmap_t), pointer	dof => null()
	SEM dofmap.
integer	les_model_registry_size = 0
	Number of custom artificial viscosity model allocators.

Detailed Description

Definition at line 48 of file avm.f90.

Member Function/Subroutine Documentation

compute()

procedure(avm_compute), deferred, pass artificial_viscosity_model::avm_t::compute ( class(avm_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

pure virtual

Definition at line 69 of file avm.f90.

free()

procedure(avm_free), deferred, pass artificial_viscosity_model::avm_t::free ( class(avm_t), intent(inout)  this )

pure virtual

Definition at line 65 of file avm.f90.

free_base()

procedure, pass(this) artificial_viscosity_model::avm_t::free_base

(

class(avm_t), intent(inout)

this

)

Parameters

this	The artificial viscosity model.

Definition at line 61 of file avm.f90.

init()

procedure(avm_init), deferred, pass artificial_viscosity_model::avm_t::init ( class(avm_t), intent(inout)  this, class(case_t), intent(inout), target  case, type(json_file), intent(inout)  json  )

pure virtual

Definition at line 63 of file avm.f90.

init_base()

procedure, pass(this) artificial_viscosity_model::avm_t::init_base	(	class(avm_t), intent(inout)	this,
		class(dofmap_t), intent(in), target	dof,
		class(coef_t), intent(in), target	coef,
		character(len=*), intent(in)	reg_coeff_name
	)

Parameters

object	The object to be allocated.
type_name	The name of the artificial viscosity model.
case	The case_t object.
json	A dictionary with parameters. Constructor for the avm_t (base) class.
this	The artificial viscosity model.
dof	Map of degrees of freedom.
coef	The SEM coefficients.
reg_coeff_name	The name of the artificial viscosity field.

Definition at line 59 of file avm.f90.

preprocess()

procedure(avm_preprocess), deferred, pass artificial_viscosity_model::avm_t::preprocess ( class(avm_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

pure virtual

Definition at line 67 of file avm.f90.

restart()

procedure, pass(this) artificial_viscosity_model::avm_t::restart	(	class(avm_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

this	The artificial viscosity model.
time	The restored time state.

Definition at line 71 of file avm.f90.

Member Data Documentation

coef

type(coef_t), pointer artificial_viscosity_model::avm_t::coef => null()

Definition at line 52 of file avm.f90.

dof

type(dofmap_t), pointer artificial_viscosity_model::avm_t::dof => null()

Definition at line 54 of file avm.f90.

les_model_registry_size

integer artificial_viscosity_model::avm_t::les_model_registry_size = 0

Definition at line 56 of file avm.f90.

reg_coeff

type(field_t), pointer artificial_viscosity_model::avm_t::reg_coeff => null()

Definition at line 50 of file avm.f90.

---

The documentation for this type was generated from the following file:

• /home/runner/work/neko/neko/src/viscous_regularization/avm/avm.f90
