Inheritance diagram for sponge_source_term::sponge_source_term_t:

Collaboration diagram for sponge_source_term::sponge_source_term_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, json, fields, coef, variable_name)
	Constructor from json.

procedure, pass(this)	init_constant (this, fields, coef, start_time, end_time, amplitudes, fringe_registry_name, bf_registry_pref, dump_fields, dump_fname, constant_values)
	Initialize a sponge with a constant baseflow.

procedure, pass(this)	init_user (this, fields, coef, start_time, end_time, amplitudes, fringe_registry_name, bf_registry_pref, dump_fields, dump_fname)
	Initialize a sponge with a baseflow imported from the initial condition.

procedure, pass(this)	init_field (this, fields, coef, start_time, end_time, amplitudes, fringe_registry_name, bf_registry_pref, dump_fields, dump_fname, file_name, interpolate, tolerance, mesh_file_name)
	Initialize a sponge with a baseflow imported from a field file.

procedure, pass(this)	init_common (this, fields, coef, start_time, end_time, amplitudes, fringe_registry_name, bf_registry_pref, dump_fields, dump_fname)
	Common constructor.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	compute_ (this, time)
	Compute the sponge field.

procedure, pass(this)	init_base (this, fields, coef, start_time, end_time)
	Constructor for the source_term_t (base) type.

procedure, pass(this)	free_base (this)
	Destructor for the source_term_t (base) type.

procedure, pass(this)	compute (this, time)
	Executes `compute_` based on time conditions.

procedure(source_term_init), deferred, pass	init (this, json, fields, coef, variable_name)
	The common constructor using a JSON object.

procedure(source_term_free), deferred, pass	free (this)
	Destructor.

procedure(source_term_compute), deferred, pass	compute_ (this, time)
	Computes the source term and adds the result to `fields`.

Public Attributes
type(field_t), pointer	u => null()
	Velocity components at current time.

type(field_t), pointer	v => null()

type(field_t), pointer	w => null()

type(field_t), pointer	u_bf => null()
	Base flow components.

type(field_t), pointer	v_bf => null()

type(field_t), pointer	w_bf => null()

character(len=1024)	bf_rgstry_pref
	Suffix for the base flow fields in the neko field registry.

logical	baseflow_set = .false.
	Flag indicating wether the baseflow has been set by the user.

logical	baseflow_is_ic = .false.
	Indicates wether the baseflow should be applied from the initial condition.

type(field_t), pointer	fringe => null()
	Fringe field. This field need to be added to the registry and filled by the user.

real(kind=rp), dimension(3)	amplitudes
	Fringe amplitude in the 3 cartesian directions.

character(len=1024)	fringe_registry_name
	Name of the fringe field in the neko field registry.

logical	dump_fields = .false.
	Wether or not to write the fringe field to disk.

character(neko_fname_len)	dump_fname
	Name of the fld file in which to dump the fields.

logical	check = .true.
	Flag to check for the existence of fringe and baseflow fields.

type(field_list_t)	fields
	The fields to be updated with the source term values.

type(coef_t), pointer	coef => null()
	Coefficients for the SEM.

real(kind=rp)	start_time = 0.0_rp
	Start time for adding the source term.

real(kind=rp)	end_time = huge(0.0_rp)
	End time for adding the source term.

Detailed Description

Definition at line 62 of file sponge_source_term.f90.

Member Function/Subroutine Documentation

◆ compute()

procedure, pass(this) source_term::source_term_t::compute	(	class(source_term_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	Time state.

Definition at line 59 of file source_term.f90.

◆ compute_() [1/2]

procedure(source_term_compute), deferred, pass source_term::source_term_t::compute_	(	class(source_term_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

pure virtualinherited

Definition at line 65 of file source_term.f90.

◆ compute_() [2/2]

procedure, pass(this) sponge_source_term::sponge_source_term_t::compute_	(	class(sponge_source_term_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

The fringe field must be added to the regisry and filled by the user according to where they want to apply the sponge. NOTE: Unfortunately this function is JSON dependent due to the initial condition being JSON dependent quite deep, there should be a nice way to get rid of that but it should take some effort.

Parameters

time	The current time state.

Definition at line 110 of file sponge_source_term.f90.

◆ free() [1/2]

procedure(source_term_free), deferred, pass source_term::source_term_t::free ( class(source_term_t), intent(inout) this )

pure virtualinherited

Definition at line 63 of file source_term.f90.

◆ free() [2/2]

procedure, pass(this) sponge_source_term::sponge_source_term_t::free ( class(sponge_source_term_t), intent(inout) this )

Definition at line 108 of file sponge_source_term.f90.

◆ free_base()

procedure, pass(this) source_term::source_term_t::free_base ( class(source_term_t), intent(inout) this )

inherited

Definition at line 57 of file source_term.f90.

◆ init() [1/2]

procedure(source_term_init), deferred, pass source_term::source_term_t::init	(	class(source_term_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		character(len=*), intent(in)	variable_name
	)

pure virtualinherited

Definition at line 61 of file source_term.f90.

◆ init() [2/2]

procedure, pass(this) sponge_source_term::sponge_source_term_t::init	(	class(sponge_source_term_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		character(len=*), intent(in)	variable_name
	)

Definition at line 94 of file sponge_source_term.f90.

◆ init_base()

procedure, pass(this) source_term::source_term_t::init_base	(	class(source_term_t), intent(inout)	this,
		type(field_list_t)	fields,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), intent(in)	start_time,
		real(kind=rp), intent(in)	end_time
	)

inherited

Parameters

fields	A list of pointers to fields to be updated by the source term.
coef	SEM coefs.
start_time	When to start adding the source term.
end_time	When to stop adding the source term.

Definition at line 55 of file source_term.f90.

◆ init_common()

procedure, pass(this) sponge_source_term::sponge_source_term_t::init_common	(	class(sponge_source_term_t), intent(inout)	this,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), intent(in)	start_time,
		real(kind=rp), intent(in)	end_time,
		real(kind=rp), dimension(:), intent(in)	amplitudes,
		character(len=*), intent(in)	fringe_registry_name,
		character(len=*), intent(in)	bf_registry_pref,
		logical, intent(in)	dump_fields,
		character(len=*), intent(in)	dump_fname
	)

Definition at line 105 of file sponge_source_term.f90.

◆ init_constant()

procedure, pass(this) sponge_source_term::sponge_source_term_t::init_constant	(	class(sponge_source_term_t), intent(inout)	this,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), intent(in)	start_time,
		real(kind=rp), intent(in)	end_time,
		real(kind=rp), dimension(:), intent(in)	amplitudes,
		character(len=*), intent(in)	fringe_registry_name,
		character(len=*), intent(in)	bf_registry_pref,
		logical, intent(in)	dump_fields,
		character(len=*), intent(in)	dump_fname,
		real(kind=rp), dimension(:), intent(in)	constant_values
	)

Definition at line 96 of file sponge_source_term.f90.

◆ init_field()

procedure, pass(this) sponge_source_term::sponge_source_term_t::init_field	(	class(sponge_source_term_t), intent(inout)	this,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), intent(in)	start_time,
		real(kind=rp), intent(in)	end_time,
		real(kind=rp), dimension(:), intent(in)	amplitudes,
		character(len=*), intent(in)	fringe_registry_name,
		character(len=*), intent(in)	bf_registry_pref,
		logical, intent(in)	dump_fields,
		character(len=*), intent(in)	dump_fname,
		character(len=*), intent(in)	file_name,
		logical, intent(in)	interpolate,
		real(kind=rp), intent(in)	tolerance,
		character(len=*), intent(inout)	mesh_file_name
	)

Definition at line 102 of file sponge_source_term.f90.

◆ init_user()

procedure, pass(this) sponge_source_term::sponge_source_term_t::init_user	(	class(sponge_source_term_t), intent(inout)	this,
		type(field_list_t), intent(in), target	fields,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), intent(in)	start_time,
		real(kind=rp), intent(in)	end_time,
		real(kind=rp), dimension(:), intent(in)	amplitudes,
		character(len=*), intent(in)	fringe_registry_name,
		character(len=*), intent(in)	bf_registry_pref,
		logical, intent(in)	dump_fields,
		character(len=*), intent(in)	dump_fname
	)

Definition at line 99 of file sponge_source_term.f90.

Member Data Documentation

◆ amplitudes

real(kind=rp), dimension(3) sponge_source_term::sponge_source_term_t::amplitudes

Definition at line 83 of file sponge_source_term.f90.

◆ baseflow_is_ic

logical sponge_source_term::sponge_source_term_t::baseflow_is_ic = .false.

Definition at line 78 of file sponge_source_term.f90.

◆ baseflow_set

logical sponge_source_term::sponge_source_term_t::baseflow_set = .false.

Definition at line 75 of file sponge_source_term.f90.

◆ bf_rgstry_pref

character(len=1024) sponge_source_term::sponge_source_term_t::bf_rgstry_pref

Definition at line 73 of file sponge_source_term.f90.

◆ check

logical sponge_source_term::sponge_source_term_t::check = .true.

Definition at line 91 of file sponge_source_term.f90.

◆ coef

type(coef_t), pointer source_term::source_term_t::coef => null()

inherited

Definition at line 48 of file source_term.f90.

◆ dump_fields

logical sponge_source_term::sponge_source_term_t::dump_fields = .false.

Definition at line 87 of file sponge_source_term.f90.

◆ dump_fname

character(neko_fname_len) sponge_source_term::sponge_source_term_t::dump_fname

Definition at line 89 of file sponge_source_term.f90.

◆ end_time

real(kind=rp) source_term::source_term_t::end_time = huge(0.0_rp)

inherited

Definition at line 52 of file source_term.f90.

◆ fields

type(field_list_t) source_term::source_term_t::fields

inherited

Definition at line 46 of file source_term.f90.

◆ fringe

type(field_t), pointer sponge_source_term::sponge_source_term_t::fringe => null()

Definition at line 81 of file sponge_source_term.f90.

◆ fringe_registry_name

character(len=1024) sponge_source_term::sponge_source_term_t::fringe_registry_name

Definition at line 85 of file sponge_source_term.f90.

◆ start_time

real(kind=rp) source_term::source_term_t::start_time = 0.0_rp

inherited

Definition at line 50 of file source_term.f90.

◆ u

type(field_t), pointer sponge_source_term::sponge_source_term_t::u => null()

Definition at line 65 of file sponge_source_term.f90.

◆ u_bf

type(field_t), pointer sponge_source_term::sponge_source_term_t::u_bf => null()

Definition at line 69 of file sponge_source_term.f90.

◆ v

type(field_t), pointer sponge_source_term::sponge_source_term_t::v => null()

Definition at line 66 of file sponge_source_term.f90.

◆ v_bf

type(field_t), pointer sponge_source_term::sponge_source_term_t::v_bf => null()

Definition at line 70 of file sponge_source_term.f90.

◆ w

type(field_t), pointer sponge_source_term::sponge_source_term_t::w => null()

Definition at line 67 of file sponge_source_term.f90.

◆ w_bf

type(field_t), pointer sponge_source_term::sponge_source_term_t::w_bf => null()

Definition at line 71 of file sponge_source_term.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/source_terms/sponge_source_term.f90
