non_normal_aligned Module Reference

Implements non_normal_aligned_t.

Data Types
type	non_normal_aligned_t
	Axis-aligned mixed Dirichlet condition in the non-normal direction. More...

Functions/Subroutines
subroutine	non_normal_aligned_init (this, coef, json)
	Construct the boundary condition from JSON.
subroutine	non_normal_aligned_init_from_components (this, coef, value)
	Construct the boundary condition from a uniform global vector.
subroutine	non_normal_aligned_set_values (this, value_x, value_y, value_z)
	Set inhomogeneous prescribed global vector components.
subroutine	non_normal_aligned_apply_scalar (this, x, n, time, strong)
	No-op scalar application.
subroutine	non_normal_aligned_apply_vector (this, x, y, z, n, time, strong)
	Apply the tangential components of the prescribed vector on the CPU.
subroutine	non_normal_aligned_apply_scalar_dev (this, x_d, time, strong, strm)
	No-op scalar application on the device.
subroutine	non_normal_aligned_apply_vector_dev (this, x_d, y_d, z_d, time, strong, strm)
	Apply the tangential components of the prescribed vector on the device.
subroutine	non_normal_aligned_get_normal_axis (this, sx, sy, sz, facet, el)
	Estimate which global axis is normal to a marked facet.
subroutine	non_normal_aligned_finalize (this)
	Finalize the boundary condition.
subroutine	non_normal_aligned_free (this)
	Free the boundary condition and its nested storage.

Function/Subroutine Documentation

non_normal_aligned_apply_scalar()

subroutine non_normal_aligned::non_normal_aligned_apply_scalar ( class(non_normal_aligned_t), intent(inout)  this, real(kind=rp), dimension(n), intent(inout)  x, integer, intent(in)  n, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong  )

private

Parameters

x	Scalar field values.
n	Number of entries in x.
time	Current time state.
strong	Whether to apply the strong form.

Definition at line 220 of file non_normal_aligned.f90.

non_normal_aligned_apply_scalar_dev()

subroutine non_normal_aligned::non_normal_aligned_apply_scalar_dev ( class(non_normal_aligned_t), intent(inout), target  this, type(c_ptr), intent(inout)  x_d, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong, type(c_ptr), intent(inout)  strm  )

private

Parameters

x_d	Device pointer to the scalar field.
time	Current time state.
strong	Whether to apply the strong form.
strm	Device stream.

Definition at line 276 of file non_normal_aligned.f90.

non_normal_aligned_apply_vector()

subroutine non_normal_aligned::non_normal_aligned_apply_vector ( class(non_normal_aligned_t), intent(inout)  this, real(kind=rp), dimension(n), intent(inout)  x, real(kind=rp), dimension(n), intent(inout)  y, real(kind=rp), dimension(n), intent(inout)  z, integer, intent(in)  n, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong  )

private

Each nested Dirichlet boundary condition contributes only its compact mask. The corresponding component values are stored in the same compact ordering as that mask.

Parameters

x	x-component of the field.
y	y-component of the field.
z	z-component of the field.
n	Number of entries in each component array.
time	Current time state.
strong	Whether to apply the strong form.

Definition at line 238 of file non_normal_aligned.f90.

non_normal_aligned_apply_vector_dev()

subroutine non_normal_aligned::non_normal_aligned_apply_vector_dev ( class(non_normal_aligned_t), intent(inout), target  this, type(c_ptr), intent(inout)  x_d, type(c_ptr), intent(inout)  y_d, type(c_ptr), intent(inout)  z_d, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong, type(c_ptr), intent(inout)  strm  )

private

Uses the compact per-component storage together with the masks of the nested Dirichlet boundary conditions.

Parameters

x_d	Device pointer to the x-component.
y_d	Device pointer to the y-component.
z_d	Device pointer to the z-component.
time	Current time state.
strong	Whether to apply the strong form.
strm	Device stream.

Definition at line 293 of file non_normal_aligned.f90.

Here is the call graph for this function:

non_normal_aligned_finalize()

subroutine non_normal_aligned::non_normal_aligned_finalize ( class(non_normal_aligned_t), intent(inout), target  this )

private

Marks the two tangential component conditions for each facet, finalizes the nested Dirichlet masks, allocates compact component-value storage, and populates it for the uniform-value case.

Definition at line 380 of file non_normal_aligned.f90.

non_normal_aligned_free()

subroutine non_normal_aligned::non_normal_aligned_free ( class(non_normal_aligned_t), intent(inout), target  this )

private

Definition at line 465 of file non_normal_aligned.f90.

non_normal_aligned_get_normal_axis()

subroutine non_normal_aligned::non_normal_aligned_get_normal_axis ( class(non_normal_aligned_t), intent(inout), target  this, real(kind=rp), intent(out)  sx, real(kind=rp), intent(out)  sy, real(kind=rp), intent(out)  sz, integer, intent(in)  facet, integer, intent(in)  el  )

private

Parameters

[out]	sx	Deviation from an x-aligned normal.
[out]	sy	Deviation from a y-aligned normal.
[out]	sz	Deviation from a z-aligned normal.
[in]	facet	Facet id on the reference hex.
[in]	el	Element id.

Definition at line 332 of file non_normal_aligned.f90.

non_normal_aligned_init()

subroutine non_normal_aligned::non_normal_aligned_init	(	class(non_normal_aligned_t), intent(inout), target	this,
		type(coef_t), intent(in), target	coef,
		type(json_file), intent(inout)	json
	)

Parameters

[in]	coef	The SEM coefficients.
[in,out]	json	The JSON object configuring the boundary condition.

Definition at line 114 of file non_normal_aligned.f90.

non_normal_aligned_init_from_components()

subroutine non_normal_aligned::non_normal_aligned_init_from_components ( class(non_normal_aligned_t), intent(inout), target  this, type(coef_t), intent(in), target  coef, real(kind=rp), dimension(3), intent(in)  value  )

private

Parameters

[in]	coef	The SEM coefficients.
[in]	value	Global vector whose tangential components are enforced.

Definition at line 164 of file non_normal_aligned.f90.

non_normal_aligned_set_values()

subroutine non_normal_aligned::non_normal_aligned_set_values ( class(non_normal_aligned_t), intent(inout)  this, type(vector_t), intent(in)  value_x, type(vector_t), intent(in)  value_y, type(vector_t), intent(in)  value_z  )

private

The vectors are stored in compact form and must match the component-wise mask sizes of bc_x, bc_y and bc_z. Therefore this routine must be called only after the nested masks have been finalized.

Parameters

[in]	value_x	Prescribed x values ordered like bc_xmsk(1:).
[in]	value_y	Prescribed y values ordered like bc_ymsk(1:).
[in]	value_z	Prescribed z values ordered like bc_zmsk(1:).

Definition at line 186 of file non_normal_aligned.f90.
