non_normal_aligned::non_normal_aligned_t Type Reference

Axis-aligned mixed Dirichlet condition in the non-normal direction. More...

Inheritance diagram for non_normal_aligned::non_normal_aligned_t:

Collaboration diagram for non_normal_aligned::non_normal_aligned_t:

Public Member Functions
procedure, pass(this)	apply_scalar (this, x, n, time, strong)
	No-op scalar application.
procedure, pass(this)	apply_vector (this, x, y, z, n, time, strong)
	Apply the tangential components of the prescribed vector on the CPU.
procedure, pass(this)	apply_scalar_dev (this, x_d, time, strong, strm)
	No-op scalar application on the device.
procedure, pass(this)	apply_vector_dev (this, x_d, y_d, z_d, time, strong, strm)
	Apply the tangential components of the prescribed vector on the device.
procedure, pass(this)	init (this, coef, json)
	Construct the boundary condition from JSON.
procedure, pass(this)	init_from_components (this, coef, value)
	Construct the boundary condition from a uniform global vector.
procedure, pass(this)	set_values (this, value_x, value_y, value_z)
	Set inhomogeneous prescribed global vector components.
procedure, pass(this)	free (this)
	Free the boundary condition and its nested storage.
procedure, pass(this)	finalize (this)
	Finalize the boundary condition.
procedure, pass(this)	get_normal_axis (this, sx, sy, sz, facet, el)
	Estimate which global axis is normal to a marked facet.
procedure, pass(this)	init_base (this, coef)
	Constructor.
procedure, pass(this)	free_base (this)
	Destructor.
procedure, pass(this)	mark_facet (this, facet, el)
	Mark a facet on an element as part of the boundary condition.
procedure, pass(this)	mark_facets (this, facet_list)
	Mark all facets from a (facet, element) tuple list.
procedure, pass(this)	mark_zone (this, bc_zone)
	Mark all facets from a zone.
procedure, pass(this)	mark_labeled_zone (this, zone_index)
	Mark all facets from a labeled zone.
procedure, pass(this)	mark_labeled_zones (this, zone_indices)
	Mark all facets from a list of labeled zones.
procedure, pass(this)	finalize_base (this)
	Finalize the construction of the bc by populating the msk and facet arrays.
procedure, pass(this)	apply_scalar_generic (this, x, time, strong, strm)
	Apply the boundary condition to a scalar field. Dispatches to the CPU or the device version.
procedure, pass(this)	apply_vector_generic (this, x, y, z, time, strong, strm)
	Apply the boundary condition to a vector field. Dispatches to the CPU or the device version.
procedure, pass(this)	debug_mask_ (this, file_name)
	Write a field showing the mask of the bcs.
procedure(bc_apply_scalar), deferred, pass	apply_scalar (this, x, n, time, strong)
	Apply the boundary condition to a scalar field on the CPU.
procedure(bc_apply_vector), deferred, pass	apply_vector (this, x, y, z, n, time, strong)
	Apply the boundary condition to a vector field on the CPU.
procedure(bc_apply_scalar_dev), deferred, pass	apply_scalar_dev (this, x_d, time, strong, strm)
	Device version of apply_scalar on the device.
procedure(bc_apply_vector_dev), deferred, pass	apply_vector_dev (this, x_d, y_d, z_d, time, strong, strm)
	Device version of apply_vector on the device.
procedure(bc_destructor), deferred, pass	free (this)
	Deferred destructor.
procedure(bc_constructor), deferred, pass	init (this, coef, json)
	Deferred constructor.
procedure(bc_finalize), deferred, pass	finalize (this)
	Deferred finalizer.

Public Attributes
type(dirichlet_t)	bc_x
	Nested dirichlet bcs for each component. Used only for their masks.
type(dirichlet_t)	bc_y
type(dirichlet_t)	bc_z
type(vector_t)	value_x
	The applied values for each component. Allocated at finalization.
type(vector_t)	value_y
type(vector_t)	value_z
integer, dimension(:), allocatable	msk
	The linear index of each constrained local degree of freedom.
integer, dimension(:), allocatable	facet_node_msk
	The linear index of each node on the marked boundary facets.
integer, dimension(:), allocatable	facet
	A list of facet ids (1 to 6), one for each entry in facet_node_msk.
type(dofmap_t), pointer	dof => null()
	Map of degrees of freedom.
type(coef_t), pointer	coef => null()
	SEM coefficients.
type(mesh_t), pointer	msh => null()
	The mesh.
type(space_t), pointer	xh => null()
	The function space.
type(stack_i4t2_t)	marked_facet
	Index tuples (facet, element) marked as part of the boundary condition.
type(c_ptr)	msk_d = C_NULL_PTR
	Device pointer for msk.
type(c_ptr)	facet_node_msk_d = C_NULL_PTR
	Device pointer for facet_node_msk.
type(c_ptr)	facet_d = C_NULL_PTR
	Device pointer for facet.
integer	bc_type = -1
	Type of the boundary condition, from the BC_* constants.
logical	updated = .false.
	Indicates wether the bc has been updated, for those BCs that need additional computations.
character(len=:), allocatable	name
integer, dimension(:), allocatable	zone_indices

Private Attributes
real(kind=rp), dimension(3), private	constant_value = 0.0_rp
	Helper to parse uniform input from the case file.
logical, private	use_constant_value = .true.
	Bookkeeping for initialization. Necessary because we can only init in finalize()
logical, private	read_values_from_field = .false.
logical, private	field_interpolate = .false.
character(len=:), allocatable, private	field_file_name
character(len=:), allocatable, private	field_mesh_file_name
real(kind=dp), private	field_interp_tolerance = GLOB_INTERP_TOL
real(kind=dp), private	field_interp_padding = GLOB_INTERP_PAD

Detailed Description

Warning

Only works for axis-aligned plane boundaries.

Since dirichlet_t currently only supports constant values, we store the values separately in vectors, and use the nested dirichlet_t only for its mask.

Definition at line 61 of file non_normal_aligned.f90.

Member Function/Subroutine Documentation

apply_scalar() [1/2]

procedure(bc_apply_scalar), deferred, pass bc::bc_t::apply_scalar ( class(bc_t), intent(inout)  this, real(kind=rp), dimension(n), intent(inout)  x, integer, intent(in)  n, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong  )

pure virtualinherited

Definition at line 132 of file bc.f90.

apply_scalar() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::apply_scalar	(	class(non_normal_aligned_t), intent(inout)	this,
		real(kind=rp), dimension(n), intent(inout)	x,
		integer, intent(in)	n,
		type(time_state_t), intent(in), optional	time,
		logical, intent(in), optional	strong
	)

Parameters

x	Scalar field values.
n	Number of entries in x.
time	Current time state.
strong	Whether to apply the strong form.

Definition at line 84 of file non_normal_aligned.f90.

apply_scalar_dev() [1/2]

procedure(bc_apply_scalar_dev), deferred, pass bc::bc_t::apply_scalar_dev ( class(bc_t), intent(inout), target  this, type(c_ptr), intent(inout)  x_d, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong, type(c_ptr), intent(inout)  strm  )

pure virtualinherited

Definition at line 136 of file bc.f90.

apply_scalar_dev() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::apply_scalar_dev	(	class(non_normal_aligned_t), intent(inout), target	this,
		type(c_ptr), intent(inout)	x_d,
		type(time_state_t), intent(in), optional	time,
		logical, intent(in), optional	strong,
		type(c_ptr), intent(inout)	strm
	)

Parameters

x_d	Device pointer to the scalar field.
time	Current time state.
strong	Whether to apply the strong form.
strm	Device stream.

Definition at line 88 of file non_normal_aligned.f90.

apply_scalar_generic()

procedure, pass(this) bc::bc_t::apply_scalar_generic ( class(bc_t), intent(inout)  this, type(field_t), intent(inout)  x, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong, type(c_ptr), intent(inout), optional  strm  )

inherited

Parameters

x	The x comp of the field for which to apply the bc.
time	Current time state.
strong	Whether we are setting a strong or a weak bc.
strm	Device stream

Definition at line 125 of file bc.f90.

apply_vector() [1/2]

procedure(bc_apply_vector), deferred, pass bc::bc_t::apply_vector ( class(bc_t), intent(inout)  this, real(kind=rp), dimension(n), intent(inout)  x, real(kind=rp), dimension(n), intent(inout)  y, real(kind=rp), dimension(n), intent(inout)  z, integer, intent(in)  n, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong  )

pure virtualinherited

Definition at line 134 of file bc.f90.

apply_vector() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::apply_vector	(	class(non_normal_aligned_t), intent(inout)	this,
		real(kind=rp), dimension(n), intent(inout)	x,
		real(kind=rp), dimension(n), intent(inout)	y,
		real(kind=rp), dimension(n), intent(inout)	z,
		integer, intent(in)	n,
		type(time_state_t), intent(in), optional	time,
		logical, intent(in), optional	strong
	)

Each nested Dirichlet boundary condition contributes only its compact mask. The corresponding component values are stored in the same compact ordering as that mask.

Parameters

x	x-component of the field.
y	y-component of the field.
z	z-component of the field.
n	Number of entries in each component array.
time	Current time state.
strong	Whether to apply the strong form.

Definition at line 86 of file non_normal_aligned.f90.

apply_vector_dev() [1/2]

procedure(bc_apply_vector_dev), deferred, pass bc::bc_t::apply_vector_dev ( class(bc_t), intent(inout), target  this, type(c_ptr), intent(inout)  x_d, type(c_ptr), intent(inout)  y_d, type(c_ptr), intent(inout)  z_d, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong, type(c_ptr), intent(inout)  strm  )

pure virtualinherited

Definition at line 138 of file bc.f90.

apply_vector_dev() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::apply_vector_dev	(	class(non_normal_aligned_t), intent(inout), target	this,
		type(c_ptr), intent(inout)	x_d,
		type(c_ptr), intent(inout)	y_d,
		type(c_ptr), intent(inout)	z_d,
		type(time_state_t), intent(in), optional	time,
		logical, intent(in), optional	strong,
		type(c_ptr), intent(inout)	strm
	)

Uses the compact per-component storage together with the masks of the nested Dirichlet boundary conditions.

Parameters

x_d	Device pointer to the x-component.
y_d	Device pointer to the y-component.
z_d	Device pointer to the z-component.
time	Current time state.
strong	Whether to apply the strong form.
strm	Device stream.

Definition at line 91 of file non_normal_aligned.f90.

apply_vector_generic()

procedure, pass(this) bc::bc_t::apply_vector_generic ( class(bc_t), intent(inout)  this, type(field_t), intent(inout)  x, type(field_t), intent(inout)  y, type(field_t), intent(inout)  z, type(time_state_t), intent(in), optional  time, logical, intent(in), optional  strong, type(c_ptr), intent(inout), optional  strm  )

inherited

Parameters

x	The x comp of the field for which to apply the bc.
y	The y comp of the field for which to apply the bc.
z	The z comp of the field for which to apply the bc.
time	Current time state.
strong	Whether we are setting a strong or a weak bc.
Device	stream

Definition at line 128 of file bc.f90.

debug_mask_()

procedure, pass(this) bc::bc_t::debug_mask_ ( class(bc_t), intent(inout)  this, character(len=*), intent(in)  file_name  )

inherited

The mask will be marked with 1.

Parameters

file_name

The name of the fld file.

Definition at line 130 of file bc.f90.

finalize() [1/2]

procedure(bc_finalize), deferred, pass bc::bc_t::finalize ( class(bc_t), intent(inout), target  this )

pure virtualinherited

Definition at line 144 of file bc.f90.

finalize() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::finalize

(

class(non_normal_aligned_t), intent(inout), target

this

)

Marks the two tangential component conditions for each facet, finalizes the nested Dirichlet masks, allocates compact component-value storage, and populates it for the uniform-value case.

Definition at line 103 of file non_normal_aligned.f90.

finalize_base()

procedure, pass(this) bc::bc_t::finalize_base ( class(bc_t), intent(inout), target  this )

inherited

This will linearize the marked facet's indicies in the msk array.

Definition at line 121 of file bc.f90.

free() [1/2]

procedure(bc_destructor), deferred, pass bc::bc_t::free ( class(bc_t), intent(inout), target  this )

pure virtualinherited

Definition at line 140 of file bc.f90.

free() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::free

(

class(non_normal_aligned_t), intent(inout), target

this

)

Definition at line 101 of file non_normal_aligned.f90.

free_base()

procedure, pass(this) bc::bc_t::free_base ( class(bc_t), intent(inout)  this )

inherited

Definition at line 108 of file bc.f90.

get_normal_axis()

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::get_normal_axis	(	class(non_normal_aligned_t), intent(inout), target	this,
		real(kind=rp), intent(out)	sx,
		real(kind=rp), intent(out)	sy,
		real(kind=rp), intent(out)	sz,
		integer, intent(in)	facet,
		integer, intent(in)	el
	)

Parameters

[out]	sx	Deviation from an x-aligned normal.
[out]	sy	Deviation from a y-aligned normal.
[out]	sz	Deviation from a z-aligned normal.
[in]	facet	Facet id on the reference hex.
[in]	el	Element id.

Definition at line 105 of file non_normal_aligned.f90.

init() [1/2]

procedure(bc_constructor), deferred, pass bc::bc_t::init ( class(bc_t), intent(inout), target  this, type(coef_t), intent(in), target  coef, type(json_file), intent(inout)  json  )

pure virtualinherited

Definition at line 142 of file bc.f90.

init() [2/2]

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::init	(	class(non_normal_aligned_t), intent(inout), target	this,
		type(coef_t), intent(in), target	coef,
		type(json_file), intent(inout)	json
	)

Parameters

[in]	coef	The SEM coefficients.
[in,out]	json	The JSON object configuring the boundary condition.

Definition at line 94 of file non_normal_aligned.f90.

init_base()

procedure, pass(this) bc::bc_t::init_base ( class(bc_t), intent(inout)  this, type(coef_t), intent(in), target  coef  )

inherited

Parameters

dof	Map of degrees of freedom.

Definition at line 106 of file bc.f90.

init_from_components()

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::init_from_components	(	class(non_normal_aligned_t), intent(inout), target	this,
		type(coef_t), intent(in), target	coef,
		real(kind=rp), dimension(3), intent(in)	value
	)

Parameters

[in]	coef	The SEM coefficients.
[in]	value	Global vector whose tangential components are enforced.

Definition at line 96 of file non_normal_aligned.f90.

mark_facet()

procedure, pass(this) bc::bc_t::mark_facet ( class(bc_t), intent(inout)  this, integer, intent(in)  facet, integer, intent(in)  el  )

inherited

Parameters

facet	The index of the facet.
el	The index of the element.

Definition at line 110 of file bc.f90.

mark_facets()

procedure, pass(this) bc::bc_t::mark_facets ( class(bc_t), intent(inout)  this, type(stack_i4t2_t), intent(inout)  facet_list  )

inherited

Parameters

facet_list

The list of tuples.

Definition at line 112 of file bc.f90.

mark_labeled_zone()

procedure, pass(this) bc::bc_t::mark_labeled_zone ( class(bc_t), intent(inout)  this, integer, intent(in)  zone_index  )

inherited

Parameters

zone_index

The index of the labeled zone to be marked.

Definition at line 116 of file bc.f90.

mark_labeled_zones()

procedure, pass(this) bc::bc_t::mark_labeled_zones ( class(bc_t), intent(inout)  this, integer, dimension(:), intent(in)  zone_indices  )

inherited

Parameters

zone_indices

The indices of the labeled zones to be marked.

Definition at line 118 of file bc.f90.

mark_zone()

procedure, pass(this) bc::bc_t::mark_zone ( class(bc_t), intent(inout)  this, class(facet_zone_t), intent(in)  bc_zone  )

inherited

Parameters

bc_zone

Boundary zone to be marked.

Definition at line 114 of file bc.f90.

set_values()

procedure, pass(this) non_normal_aligned::non_normal_aligned_t::set_values	(	class(non_normal_aligned_t), intent(inout)	this,
		type(vector_t), intent(in)	value_x,
		type(vector_t), intent(in)	value_y,
		type(vector_t), intent(in)	value_z
	)

The vectors are stored in compact form and must match the component-wise mask sizes of bc_x, bc_y and bc_z. Therefore this routine must be called only after the nested masks have been finalized.

Parameters

[in]	value_x	Prescribed x values ordered like bc_xmsk(1:).
[in]	value_y	Prescribed y values ordered like bc_ymsk(1:).
[in]	value_z	Prescribed z values ordered like bc_zmsk(1:).

Definition at line 99 of file non_normal_aligned.f90.

Member Data Documentation

bc_type

integer bc::bc_t::bc_type = -1

inherited

Definition at line 96 of file bc.f90.

bc_x

type(dirichlet_t) non_normal_aligned::non_normal_aligned_t::bc_x

Definition at line 63 of file non_normal_aligned.f90.

bc_y

type(dirichlet_t) non_normal_aligned::non_normal_aligned_t::bc_y

Definition at line 64 of file non_normal_aligned.f90.

bc_z

type(dirichlet_t) non_normal_aligned::non_normal_aligned_t::bc_z

Definition at line 65 of file non_normal_aligned.f90.

coef

type(coef_t), pointer bc::bc_t::coef => null()

inherited

Definition at line 82 of file bc.f90.

constant_value

real(kind=rp), dimension(3), private non_normal_aligned::non_normal_aligned_t::constant_value = 0.0_rp

private

Definition at line 71 of file non_normal_aligned.f90.

dof

type(dofmap_t), pointer bc::bc_t::dof => null()

inherited

Definition at line 80 of file bc.f90.

facet

integer, dimension(:), allocatable bc::bc_t::facet

inherited

Definition at line 78 of file bc.f90.

facet_d

type(c_ptr) bc::bc_t::facet_d = C_NULL_PTR

inherited

Definition at line 94 of file bc.f90.

facet_node_msk

integer, dimension(:), allocatable bc::bc_t::facet_node_msk

inherited

Definition at line 76 of file bc.f90.

facet_node_msk_d

type(c_ptr) bc::bc_t::facet_node_msk_d = C_NULL_PTR

inherited

Definition at line 92 of file bc.f90.

field_file_name

character(len=:), allocatable, private non_normal_aligned::non_normal_aligned_t::field_file_name

private

Definition at line 78 of file non_normal_aligned.f90.

field_interp_padding

real(kind=dp), private non_normal_aligned::non_normal_aligned_t::field_interp_padding = GLOB_INTERP_PAD

private

Definition at line 81 of file non_normal_aligned.f90.

field_interp_tolerance

real(kind=dp), private non_normal_aligned::non_normal_aligned_t::field_interp_tolerance = GLOB_INTERP_TOL

private

Definition at line 80 of file non_normal_aligned.f90.

field_interpolate

logical, private non_normal_aligned::non_normal_aligned_t::field_interpolate = .false.

private

Definition at line 77 of file non_normal_aligned.f90.

field_mesh_file_name

character(len=:), allocatable, private non_normal_aligned::non_normal_aligned_t::field_mesh_file_name

private

Definition at line 79 of file non_normal_aligned.f90.

marked_facet

type(stack_i4t2_t) bc::bc_t::marked_facet

inherited

Definition at line 88 of file bc.f90.

msh

type(mesh_t), pointer bc::bc_t::msh => null()

inherited

Definition at line 84 of file bc.f90.

msk

integer, dimension(:), allocatable bc::bc_t::msk

inherited

Definition at line 74 of file bc.f90.

msk_d

type(c_ptr) bc::bc_t::msk_d = C_NULL_PTR

inherited

Definition at line 90 of file bc.f90.

name

character(len=:), allocatable bc::bc_t::name

inherited

Definition at line 101 of file bc.f90.

read_values_from_field

logical, private non_normal_aligned::non_normal_aligned_t::read_values_from_field = .false.

private

Definition at line 76 of file non_normal_aligned.f90.

updated

logical bc::bc_t::updated = .false.

inherited

Definition at line 99 of file bc.f90.

use_constant_value

logical, private non_normal_aligned::non_normal_aligned_t::use_constant_value = .true.

private

Definition at line 75 of file non_normal_aligned.f90.

value_x

type(vector_t) non_normal_aligned::non_normal_aligned_t::value_x

Definition at line 67 of file non_normal_aligned.f90.

value_y

type(vector_t) non_normal_aligned::non_normal_aligned_t::value_y

Definition at line 68 of file non_normal_aligned.f90.

value_z

type(vector_t) non_normal_aligned::non_normal_aligned_t::value_z

Definition at line 69 of file non_normal_aligned.f90.

xh

type(space_t), pointer bc::bc_t::xh => null()

inherited

Definition at line 86 of file bc.f90.

zone_indices

integer, dimension(:), allocatable bc::bc_t::zone_indices

inherited

Definition at line 103 of file bc.f90.

---

The documentation for this type was generated from the following file:

• /home/runner/work/neko/neko/src/bc/non_normal_aligned.f90
