A simulation component that computes the weak gradient of a field. Wraps the opgradient operator. More...

Inheritance diagram for weak_gradient_simcomp::weak_gradient_t:

Collaboration diagram for weak_gradient_simcomp::weak_gradient_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, json, case)
	Constructor from json, wrapping the actual constructor.

generic	init_from_components (this, case, order, preprocess_controller, compute_controller, output_controller, field_name, computed_field, filename, precision)
	Generic for constructing from components.

generic	init_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, field_name, computed_field, filename, precision)
	Generic for constructing from components.

procedure, pass(this)	init_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller, field_name, computed_field, filename, precision)
	Constructor from components, passing time_based_controllers.

procedure, pass(this)	init_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, field_name, computed_field, filename, precision)
	Constructor from components, passing the properties of time_based_controllers.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	compute_ (this, time)
	Compute the weak_gradient field.

procedure, pass(this)	init_base (this, json, case)
	Constructor for the simulation_component_t (base) class.

generic	init_base_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from components.

generic	init_base_from_components (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from components.

procedure, pass(this)	init_base_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from time_based_controllers, essentially directly from all components (we reserve the `_from_components` name for the generic binding).

procedure, pass(this)	init_base_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from properties of time_based_controllers, so the latter are constructed instead of assigned.

procedure, pass(this)	free_base (this)
	Destructor for the simulation_component_t (base) class.

procedure, pass(this)	restart (this, time)
	Wrapper for calling `set_counter` for the time based controllers. Serves as the public interface.

procedure, pass(this)	preprocess (this, time)
	Wrapper for calling `preprocess_` based on the `preprocess_controller`. Serves as the public interface.

procedure, pass(this)	compute (this, time)
	Wrapper for calling `compute_` based on the `compute_controller`. Serves as the public interface.

procedure(simulation_component_init), deferred, pass	init (this, json, case)
	The common constructor using a JSON dictionary.

procedure(simulation_component_free), deferred, pass	free (this)
	Destructor.

procedure, pass(this)	preprocess_ (this, time)
	The preprocessing function to be executed during the run.

procedure, pass(this)	compute_ (this, time)
	The main function to be executed during the run.

procedure, pass(this)	restart_ (this, time)
	The restart function to be called upon restarting simulation.

procedure, pass(this)	parse_json (this, json, case_params, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	JSON parameter parser for the time-based controllers.

Public Attributes
type(field_t), pointer	u
	The scalar field to compute the weak gradient of.

type(field_t), pointer	gradient_x
	X weak gradient component.

type(field_t), pointer	gradient_y
	Y weak gradient component.

type(field_t), pointer	gradient_z
	Z weak gradient component.

type(field_writer_t)	writer
	Output writer.

type(case_t), pointer	case
	Pointer to the simulation case.

type(time_based_controller_t)	preprocess_controller
	Controller for when to run `preprocess`.

type(time_based_controller_t)	compute_controller
	Controller for when to run `compute`.

type(time_based_controller_t)	output_controller
	Controller for when to do output.

integer	order
	The execution order, lowest excutes first.

Private Member Functions
procedure, pass(this), private	init_common (this, field_name, computed_field)
	Common part of both constructors.

Detailed Description

Definition at line 54 of file weak_gradient_simcomp.f90.

Member Function/Subroutine Documentation

◆ compute()

procedure, pass(this) simulation_component::simulation_component_t::compute	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 88 of file simulation_component.f90.

◆ compute_() [1/2]

procedure, pass(this) simulation_component::simulation_component_t::compute_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 96 of file simulation_component.f90.

◆ compute_() [2/2]

procedure, pass(this) weak_gradient_simcomp::weak_gradient_t::compute_	(	class(weak_gradient_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

time	The current time value

Definition at line 84 of file weak_gradient_simcomp.f90.

◆ free() [1/2]

procedure(simulation_component_free), deferred, pass simulation_component::simulation_component_t::free ( class(simulation_component_t), intent(inout) this )

pure virtualinherited

Definition at line 92 of file simulation_component.f90.

◆ free() [2/2]

procedure, pass(this) weak_gradient_simcomp::weak_gradient_t::free ( class(weak_gradient_t), intent(inout) this )

Definition at line 82 of file weak_gradient_simcomp.f90.

◆ free_base()

procedure, pass(this) simulation_component::simulation_component_t::free_base ( class(simulation_component_t), intent(inout) this )

inherited

Definition at line 78 of file simulation_component.f90.

◆ init() [1/2]

procedure(simulation_component_init), deferred, pass simulation_component::simulation_component_t::init	(	class(simulation_component_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

pure virtualinherited

Definition at line 90 of file simulation_component.f90.

◆ init() [2/2]

procedure, pass(this) weak_gradient_simcomp::weak_gradient_t::init	(	class(weak_gradient_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

Definition at line 68 of file weak_gradient_simcomp.f90.

◆ init_base()

procedure, pass(this) simulation_component::simulation_component_t::init_base	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

inherited

Definition at line 62 of file simulation_component.f90.

◆ init_base_from_components() [1/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 64 of file simulation_component.f90.

◆ init_base_from_components() [2/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 64 of file simulation_component.f90.

◆ init_base_from_controllers()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 70 of file simulation_component.f90.

◆ init_base_from_controllers_properties()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers_properties	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 75 of file simulation_component.f90.

◆ init_common()

procedure, pass(this), private weak_gradient_simcomp::weak_gradient_t::init_common	(	class(weak_gradient_t), intent(inout)	this,
		character(len=*)	field_name,
		character(len=*)	computed_field
	)

private

Definition at line 80 of file weak_gradient_simcomp.f90.

◆ init_from_components() [1/2]

generic weak_gradient_simcomp::weak_gradient_t::init_from_components	(	class(weak_gradient_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*)	field_name,
		character(len=*)	computed_field,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
field_name	The name of the field to compute the weak_gradient of.
computed_field	The base name of the weak_gradient field components.
filename	The name of the file save the fields to. Optional, if not provided, fields are added to the main output file.
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 70 of file weak_gradient_simcomp.f90.

◆ init_from_components() [2/2]

generic weak_gradient_simcomp::weak_gradient_t::init_from_components	(	class(weak_gradient_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*)	field_name,
		character(len=*)	computed_field,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
field_name	The name of the field to compute the weak_gradient of.
computed_field	The base name of the weak_gradient field components.
filename	The name of the file save the fields to. Optional, if not
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 70 of file weak_gradient_simcomp.f90.

◆ init_from_controllers()

procedure, pass(this) weak_gradient_simcomp::weak_gradient_t::init_from_controllers	(	class(weak_gradient_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*)	field_name,
		character(len=*)	computed_field,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
field_name	The name of the field to compute the weak_gradient of.
computed_field	The base name of the weak_gradient field components.
filename	The name of the file save the fields to. Optional, if not
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 73 of file weak_gradient_simcomp.f90.

◆ init_from_controllers_properties()

procedure, pass(this) weak_gradient_simcomp::weak_gradient_t::init_from_controllers_properties	(	class(weak_gradient_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*)	field_name,
		character(len=*)	computed_field,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
field_name	The name of the field to compute the weak_gradient of.
computed_field	The base name of the weak_gradient field components.
filename	The name of the file save the fields to. Optional, if not provided, fields are added to the main output file.
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 77 of file weak_gradient_simcomp.f90.

◆ parse_json()

procedure, pass(this) simulation_component::simulation_component_t::parse_json	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(json_file), intent(inout)	case_params,
		character(len=:), intent(inout), allocatable	preprocess_control,
		real(kind=rp), intent(out)	preprocess_value,
		character(len=:), intent(inout), allocatable	compute_control,
		real(kind=rp), intent(out)	compute_value,
		character(len=:), intent(inout), allocatable	output_control,
		real(kind=rp), intent(out)	output_value
	)

inherited

Parameters

json	The JSON dictionary of the simcomp.
case_params	The entire case configuration JSON.
preprocess_value	Control mode for preprocessing.
preprocess_controller	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_controller	Value parameter for computing.
output_controller	Control mode for output.
output_controller	Value parameter for output.

Definition at line 100 of file simulation_component.f90.

◆ preprocess()

procedure, pass(this) simulation_component::simulation_component_t::preprocess	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 84 of file simulation_component.f90.

◆ preprocess_()

procedure, pass(this) simulation_component::simulation_component_t::preprocess_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 94 of file simulation_component.f90.

◆ restart()

procedure, pass(this) simulation_component::simulation_component_t::restart	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 81 of file simulation_component.f90.

◆ restart_()

procedure, pass(this) simulation_component::simulation_component_t::restart_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 98 of file simulation_component.f90.

Member Data Documentation

◆ case

type(case_t), pointer simulation_component::simulation_component_t::case

inherited

Definition at line 51 of file simulation_component.f90.

◆ compute_controller

type(time_based_controller_t) simulation_component::simulation_component_t::compute_controller

inherited

Definition at line 55 of file simulation_component.f90.

◆ gradient_x

type(field_t), pointer weak_gradient_simcomp::weak_gradient_t::gradient_x

Definition at line 58 of file weak_gradient_simcomp.f90.

◆ gradient_y

type(field_t), pointer weak_gradient_simcomp::weak_gradient_t::gradient_y

Definition at line 60 of file weak_gradient_simcomp.f90.

◆ gradient_z

type(field_t), pointer weak_gradient_simcomp::weak_gradient_t::gradient_z

Definition at line 62 of file weak_gradient_simcomp.f90.

◆ order

integer simulation_component::simulation_component_t::order

inherited

Definition at line 59 of file simulation_component.f90.

◆ output_controller

type(time_based_controller_t) simulation_component::simulation_component_t::output_controller

inherited

Definition at line 57 of file simulation_component.f90.

◆ preprocess_controller

type(time_based_controller_t) simulation_component::simulation_component_t::preprocess_controller

inherited

Definition at line 53 of file simulation_component.f90.

◆ u

type(field_t), pointer weak_gradient_simcomp::weak_gradient_t::u

Definition at line 56 of file weak_gradient_simcomp.f90.

◆ writer

type(field_writer_t) weak_gradient_simcomp::weak_gradient_t::writer

Definition at line 64 of file weak_gradient_simcomp.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/simulation_components/weak_gradient_simcomp.f90

Public Member Functions

Public Attributes

Private Member Functions

Detailed Description

Member Function/Subroutine Documentation

◆ compute()

◆ compute_() [1/2]

◆ compute_() [2/2]

◆ free() [1/2]

◆ free() [2/2]

◆ free_base()

◆ init() [1/2]

◆ init() [2/2]

◆ init_base()

◆ init_base_from_components() [1/2]

◆ init_base_from_components() [2/2]

◆ init_base_from_controllers()

◆ init_base_from_controllers_properties()

◆ init_common()

◆ init_from_components() [1/2]

◆ init_from_components() [2/2]

◆ init_from_controllers()

◆ init_from_controllers_properties()

◆ parse_json()

◆ preprocess()

◆ preprocess_()

◆ restart()

◆ restart_()

Member Data Documentation

◆ case

◆ compute_controller

◆ gradient_x

◆ gradient_y

◆ gradient_z

◆ order

◆ output_controller

◆ preprocess_controller

◆ u

◆ writer
