scratch_registry::scratch_registry_t Interface Reference

Collaboration diagram for scratch_registry::scratch_registry_t:

Public Member Functions
procedure, pass(this)	free (this)
	destructor
procedure, pass(this)	get_nfields (this)
	getter for nfields
procedure, pass(this)	get_nfields_inuse (this)
	getter for nfields_inuse
procedure, pass(this)	get_expansion_size (this)
	getter for expansion_size
procedure, pass(this)	get_size (this)
	return size of allocated fields
procedure, pass(this)	get_inuse (this, index)
	get value of inuse for a given index
procedure, pass(this)	request_field (this, f, index)
	get a new scratch field
procedure, pass(this)	relinquish_field_single (this, index)
	Relinquish the use of a field in the registry.
procedure, pass(this)	relinquish_field_multiple (this, indices)
generic	relinquish_field (this, index)
	free a field for later reuse
generic	relinquish_field (this, indices)
	free a field for later reuse

Public Attributes
type(dofmap_t), pointer	dof => null()
	Dofmap.

Private Member Functions
procedure, pass(this), private	expand (this)

Private Attributes
type(field_ptr_t), dimension(:), allocatable, private	fields
	list of scratch fields
logical, dimension(:), allocatable, private	inuse
	Tracks which fields are used.
integer, private	nfields
	number of registered fields
integer, private	nfields_inuse
	number of fields in use
integer, private	expansion_size
	the size the fields array is increased by upon reallocation

Detailed Description

Definition at line 44 of file scratch_registry.f90.

Member Function/Subroutine Documentation

expand()

procedure, pass(this), private scratch_registry::scratch_registry_t::expand ( class(scratch_registry_t), intent(inout)  this )

private

Definition at line 58 of file scratch_registry.f90.

free()

procedure, pass(this) scratch_registry::scratch_registry_t::free

(

class(scratch_registry_t), intent(inout)

this

)

Definition at line 60 of file scratch_registry.f90.

get_expansion_size()

procedure, pass(this) scratch_registry::scratch_registry_t::get_expansion_size

(

class(scratch_registry_t), intent(in)

this

)

Definition at line 66 of file scratch_registry.f90.

get_inuse()

procedure, pass(this) scratch_registry::scratch_registry_t::get_inuse	(	class(scratch_registry_t), intent(inout), target	this,
		integer, intent(inout)	index
	)

Parameters

[in,out]

index

The index of the field to check

Definition at line 70 of file scratch_registry.f90.

get_nfields()

procedure, pass(this) scratch_registry::scratch_registry_t::get_nfields

(

class(scratch_registry_t), intent(in)

this

)

Definition at line 62 of file scratch_registry.f90.

get_nfields_inuse()

procedure, pass(this) scratch_registry::scratch_registry_t::get_nfields_inuse

(

class(scratch_registry_t), intent(in)

this

)

Definition at line 64 of file scratch_registry.f90.

get_size()

procedure, pass(this) scratch_registry::scratch_registry_t::get_size

(

class(scratch_registry_t), intent(in)

this

)

Definition at line 68 of file scratch_registry.f90.

relinquish_field() [1/2]

generic scratch_registry::scratch_registry_t::relinquish_field	(	class(scratch_registry_t), intent(inout), target	this,
		integer, intent(inout)	index
	)

Parameters

[in,out]

index

The index of the field to free

Definition at line 76 of file scratch_registry.f90.

Here is the call graph for this function:

relinquish_field() [2/2]

generic scratch_registry::scratch_registry_t::relinquish_field	(	class(scratch_registry_t), intent(inout), target	this,
		integer, dimension(:), intent(inout)	indices
	)

Parameters

[in,out]

indices

The indices of the field to free

Definition at line 76 of file scratch_registry.f90.

relinquish_field_multiple()

procedure, pass(this) scratch_registry::scratch_registry_t::relinquish_field_multiple	(	class(scratch_registry_t), intent(inout), target	this,
		integer, dimension(:), intent(inout)	indices
	)

Parameters

[in,out]

indices

The indices of the field to free

Definition at line 74 of file scratch_registry.f90.

relinquish_field_single()

procedure, pass(this) scratch_registry::scratch_registry_t::relinquish_field_single	(	class(scratch_registry_t), intent(inout), target	this,
		integer, intent(inout)	index
	)

Parameters

[in,out]

index

The index of the field to free

Definition at line 73 of file scratch_registry.f90.

request_field()

procedure, pass(this) scratch_registry::scratch_registry_t::request_field	(	class(scratch_registry_t), intent(inout), target	this,
		type(field_t), intent(inout), pointer	f,
		integer, intent(inout)	index
	)

Parameters

[in,out]

index

The index of the field in the inuse array

Definition at line 72 of file scratch_registry.f90.

Member Data Documentation

dof

type(dofmap_t), pointer scratch_registry::scratch_registry_t::dof => null()

Definition at line 56 of file scratch_registry.f90.

expansion_size

integer, private scratch_registry::scratch_registry_t::expansion_size

private

Definition at line 54 of file scratch_registry.f90.

fields

type(field_ptr_t), dimension(:), allocatable, private scratch_registry::scratch_registry_t::fields

private

Definition at line 46 of file scratch_registry.f90.

inuse

logical, dimension(:), allocatable, private scratch_registry::scratch_registry_t::inuse

private

Definition at line 48 of file scratch_registry.f90.

nfields

integer, private scratch_registry::scratch_registry_t::nfields

private

Definition at line 50 of file scratch_registry.f90.

nfields_inuse

integer, private scratch_registry::scratch_registry_t::nfields_inuse

private

Definition at line 52 of file scratch_registry.f90.

---

The documentation for this interface was generated from the following file:

• /home/runner/work/neko/neko/src/field/scratch_registry.f90
