A simulation component that computes the wall shear stress on one or more labelled boundary zones and registers it in the neko_registry. The result is written into the registry fields <computed_field>_x, _y, _z and _mag, which are zero away from the marked zones. More...

Inheritance diagram for wall_shear_stress_simcomp::wall_shear_stress_t:

[legend]

Collaboration diagram for wall_shear_stress_simcomp::wall_shear_stress_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, json, case)
	Constructors.

generic	init_from_components (this, name, case, order, preprocess_controller, compute_controller, output_controller, computed_field, viscosity_field, zone_indices, components, coef)
	Constructor from components, passing controllers.

generic	init_from_components (this, name, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, computed_field, viscosity_field, zone_indices, components, coef)
	Constructor from components, passing properties to the `time_based_controller` components in the base type.

procedure, pass(this)	init_from_controllers (this, name, case, order, preprocess_controller, compute_controller, output_controller, computed_field, viscosity_field, zone_indices, components, coef)
	Constructor from components, passing controllers.

procedure, pass(this)	init_from_controllers_properties (this, name, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, computed_field, viscosity_field, zone_indices, components, coef)
	Constructor from components, passing properties to the `time_based_controller` components in the base type.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	compute_ (this, time)
	Compute the wall shear stress.

procedure, pass(this)	init_base (this, json, case)
	Constructor for the simulation_component_t (base) class.

generic	init_base_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from components.

generic	init_base_from_components (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from components.

procedure, pass(this)	init_base_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from time_based_controllers, essentially directly from all components (we reserve the `_from_components` name for the generic binding).

procedure, pass(this)	init_base_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from properties of time_based_controllers, so the latter are constructed instead of assigned.

procedure, pass(this)	free_base (this)
	Destructor for the simulation_component_t (base) class.

procedure, pass(this)	restart (this, time)
	Wrapper for calling `set_counter` for the time based controllers. Serves as the public interface.

procedure, pass(this)	preprocess (this, time)
	Wrapper for calling `preprocess_` based on the `preprocess_controller`. Serves as the public interface.

procedure, pass(this)	compute (this, time)
	Wrapper for calling `compute_` based on the `compute_controller`. Serves as the public interface.

procedure(simulation_component_init), deferred, pass	init (this, json, case)
	The common constructor using a JSON dictionary.

procedure(simulation_component_free), deferred, pass	free (this)
	Destructor.

procedure, pass(this)	preprocess_ (this, time)
	The preprocessing function to be executed during the run.

procedure, pass(this)	compute_ (this, time)
	The main function to be executed during the run.

procedure, pass(this)	restart_ (this, time)
	The restart function to be called upon restarting simulation.

procedure, pass(this)	parse_json (this, json, case_params, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	JSON parameter parser for the time-based controllers.

Public Attributes
type(field_t), pointer	u => null()
	X velocity component.

type(field_t), pointer	v => null()
	Y velocity component.

type(field_t), pointer	w => null()
	Z velocity component.

type(field_t), pointer	p => null()
	Pressure.

type(field_t), pointer	mu => null()
	Dynamic viscosity.

type(field_t), pointer	tau_x => null()
	X component of the wall shear stress.

type(field_t), pointer	tau_y => null()
	Y component of the wall shear stress.

type(field_t), pointer	tau_z => null()
	Z component of the wall shear stress.

type(field_t), pointer	tau_mag => null()
	Magnitude of the wall shear stress.

type(coef_t), pointer	coef => null()
	SEM coefficients.

type(boundary_data_t)	bdata
	Boundary points of the chosen zones, with their geometry. Built with the `coef` normal convention, pointing out of the fluid.

integer, dimension(:), allocatable	zone_indices
	Labelled zones to include.

logical	want_x = .true.
	Which traction components are registered as fields.

logical	want_y = .true.

logical	want_z = .true.

logical	want_mag = .true.

logical	mesh_has_changed = .false.
	Whether the mesh geometry changes during the run.

character(len=:), allocatable	computed_field
	Base name of the registered fields.

type(case_t), pointer	case
	Pointer to the simulation case.

type(time_based_controller_t)	preprocess_controller
	Controller for when to run `preprocess`.

type(time_based_controller_t)	compute_controller
	Controller for when to run `compute`.

type(time_based_controller_t)	output_controller
	Controller for when to do output.

integer	order
	The execution order, lowest excutes first.

character(:), allocatable	name
	Unique name of the simcomp.

Private Member Functions
procedure, pass(this), private	init_common (this, name, computed_field, viscosity_field, zone_indices, components, coef)
	Common part of all constructors.

Detailed Description

Definition at line 63 of file wall_shear_stress_simcomp.f90.

Member Function/Subroutine Documentation

◆ compute()

procedure, pass(this) simulation_component::simulation_component_t::compute	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 91 of file simulation_component.f90.

◆ compute_() [1/2]

procedure, pass(this) simulation_component::simulation_component_t::compute_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 99 of file simulation_component.f90.

◆ compute_() [2/2]

procedure, pass(this) wall_shear_stress_simcomp::wall_shear_stress_t::compute_	(	class(wall_shear_stress_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

time	The current time state.

Definition at line 112 of file wall_shear_stress_simcomp.f90.

◆ free() [1/2]

procedure(simulation_component_free), deferred, pass simulation_component::simulation_component_t::free ( class(simulation_component_t), intent(inout) this )

pure virtualinherited

Definition at line 95 of file simulation_component.f90.

◆ free() [2/2]

procedure, pass(this) wall_shear_stress_simcomp::wall_shear_stress_t::free ( class(wall_shear_stress_t), intent(inout) this )

Definition at line 110 of file wall_shear_stress_simcomp.f90.

◆ free_base()

procedure, pass(this) simulation_component::simulation_component_t::free_base ( class(simulation_component_t), intent(inout) this )

inherited

Definition at line 81 of file simulation_component.f90.

◆ init() [1/2]

procedure(simulation_component_init), deferred, pass simulation_component::simulation_component_t::init	(	class(simulation_component_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

pure virtualinherited

Definition at line 93 of file simulation_component.f90.

◆ init() [2/2]

procedure, pass(this) wall_shear_stress_simcomp::wall_shear_stress_t::init	(	class(wall_shear_stress_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

Parameters

json	JSON object with the parameters.
case	The case object.

Definition at line 100 of file wall_shear_stress_simcomp.f90.

◆ init_base()

procedure, pass(this) simulation_component::simulation_component_t::init_base	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

inherited

Definition at line 65 of file simulation_component.f90.

◆ init_base_from_components() [1/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 67 of file simulation_component.f90.

◆ init_base_from_components() [2/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 67 of file simulation_component.f90.

◆ init_base_from_controllers()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 73 of file simulation_component.f90.

◆ init_base_from_controllers_properties()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers_properties	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 78 of file simulation_component.f90.

◆ init_common()

procedure, pass(this), private wall_shear_stress_simcomp::wall_shear_stress_t::init_common	(	class(wall_shear_stress_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		character(len=*), intent(in)	computed_field,
		character(len=*), intent(in)	viscosity_field,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), dimension(:), intent(in)	components,
		type(coef_t), intent(inout), target	coef
	)

private

Parameters

name	The unique name of the simcomp.
computed_field	The base name of the registered fields.
viscosity_field	The name of the registered viscosity field.
zone_indices	Labelled zones to include.
components	The components to register: "x", "y", "z", "mag", "all".
coef	The SEM coefficients.

Definition at line 107 of file wall_shear_stress_simcomp.f90.

◆ init_from_components() [1/2]

generic wall_shear_stress_simcomp::wall_shear_stress_t::init_from_components	(	class(wall_shear_stress_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*), intent(in)	computed_field,
		character(len=*), intent(in)	viscosity_field,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), dimension(:), intent(in)	components,
		type(coef_t), intent(inout), target	coef
	)

Parameters

name	The unique name of the simcomp.
case	The simulation case object.
order	The execution order priority of the simcomp.
preprocess_control	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_control	Control mode for computing.
compute_value	Value parameter for computing.
output_control	Control mode for output.
output_value	Value parameter for output.
computed_field	The base name of the registered fields.
viscosity_field	The name of the registered viscosity field.
zone_indices	Labelled zones to include.
components	The components to register: "x", "y", "z", "mag", "all".
coef	The SEM coefficients.

Definition at line 101 of file wall_shear_stress_simcomp.f90.

◆ init_from_components() [2/2]

generic wall_shear_stress_simcomp::wall_shear_stress_t::init_from_components	(	class(wall_shear_stress_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*), intent(in)	computed_field,
		character(len=*), intent(in)	viscosity_field,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), dimension(:), intent(in)	components,
		type(coef_t), intent(inout), target	coef
	)

Parameters

name	The unique name of the simcomp.
case	The simulation case object.
order	The execution order priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
computed_field	The base name of the registered fields.
viscosity_field	The name of the registered viscosity field.
zone_indices	Labelled zones to include.
components	The components to register: "x", "y", "z", "mag", "all".
coef	The SEM coefficients.

Definition at line 101 of file wall_shear_stress_simcomp.f90.

◆ init_from_controllers()

procedure, pass(this) wall_shear_stress_simcomp::wall_shear_stress_t::init_from_controllers	(	class(wall_shear_stress_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*), intent(in)	computed_field,
		character(len=*), intent(in)	viscosity_field,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), dimension(:), intent(in)	components,
		type(coef_t), intent(inout), target	coef
	)

Parameters

name	The unique name of the simcomp.
case	The simulation case object.
order	The execution order priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
computed_field	The base name of the registered fields.
viscosity_field	The name of the registered viscosity field.
zone_indices	Labelled zones to include.
components	The components to register: "x", "y", "z", "mag", "all".
coef	The SEM coefficients.

Definition at line 103 of file wall_shear_stress_simcomp.f90.

◆ init_from_controllers_properties()

procedure, pass(this) wall_shear_stress_simcomp::wall_shear_stress_t::init_from_controllers_properties	(	class(wall_shear_stress_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*), intent(in)	computed_field,
		character(len=*), intent(in)	viscosity_field,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), dimension(:), intent(in)	components,
		type(coef_t), intent(inout), target	coef
	)

Parameters

name	The unique name of the simcomp.
case	The simulation case object.
order	The execution order priority of the simcomp.
preprocess_control	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_control	Control mode for computing.
compute_value	Value parameter for computing.
output_control	Control mode for output.
output_value	Value parameter for output.
computed_field	The base name of the registered fields.
viscosity_field	The name of the registered viscosity field.
zone_indices	Labelled zones to include.
components	The components to register: "x", "y", "z", "mag", "all".
coef	The SEM coefficients.

Definition at line 105 of file wall_shear_stress_simcomp.f90.

◆ parse_json()

procedure, pass(this) simulation_component::simulation_component_t::parse_json	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(json_file), intent(inout)	case_params,
		character(len=:), intent(inout), allocatable	preprocess_control,
		real(kind=rp), intent(out)	preprocess_value,
		character(len=:), intent(inout), allocatable	compute_control,
		real(kind=rp), intent(out)	compute_value,
		character(len=:), intent(inout), allocatable	output_control,
		real(kind=rp), intent(out)	output_value
	)

inherited

Parameters

json	The JSON dictionary of the simcomp.
case_params	The entire case configuration JSON.
preprocess_value	Control mode for preprocessing.
preprocess_controller	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_controller	Value parameter for computing.
output_controller	Control mode for output.
output_controller	Value parameter for output.

Definition at line 103 of file simulation_component.f90.

◆ preprocess()

procedure, pass(this) simulation_component::simulation_component_t::preprocess	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 87 of file simulation_component.f90.

◆ preprocess_()

procedure, pass(this) simulation_component::simulation_component_t::preprocess_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 97 of file simulation_component.f90.

◆ restart()

procedure, pass(this) simulation_component::simulation_component_t::restart	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 84 of file simulation_component.f90.

◆ restart_()

procedure, pass(this) simulation_component::simulation_component_t::restart_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)
