boundary_operation::boundary_operation_t Type Reference

A simulation component for boundary reductions on labelled zones. More...

Inheritance diagram for boundary_operation::boundary_operation_t:

Collaboration diagram for boundary_operation::boundary_operation_t:

Public Member Functions
procedure, pass(this)	init (this, json, case)
	Construct the component from a case-file JSON object.
generic	init_from_components (this, name, case, order, preprocess_controller, compute_controller, output_controller, zone_indices, field_name, operations, log, output_filename)
	Generic constructor from components.
generic	init_from_components (this, name, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, zone_indices, field_name, operations, log, output_filename)
	Generic constructor from components.
procedure, pass(this)	init_from_controllers (this, name, case, order, preprocess_controller, compute_controller, output_controller, zone_indices, field_name, operations, log, output_filename)
	Construct from explicit time-based controllers.
procedure, pass(this)	init_from_controllers_properties (this, name, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, zone_indices, field_name, operations, log, output_filename)
	Construct from time-based controller properties.
procedure, pass(this)	free (this)
	Free the component.
procedure, pass(this)	compute_ (this, time)
	Compute the requested boundary operations.
procedure, pass(this)	init_base (this, json, case)
	Constructor for the simulation_component_t (base) class.
generic	init_base_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from components.
generic	init_base_from_components (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from components.
procedure, pass(this)	init_base_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from time_based_controllers, essentially directly from all components (we reserve the _from_components name for the generic binding).
procedure, pass(this)	init_base_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from properties of time_based_controllers, so the latter are constructed instead of assigned.
procedure, pass(this)	free_base (this)
	Destructor for the simulation_component_t (base) class.
procedure, pass(this)	restart (this, time)
	Wrapper for calling set_counter for the time based controllers. Serves as the public interface.
procedure, pass(this)	preprocess (this, time)
	Wrapper for calling preprocess_ based on the preprocess_controller. Serves as the public interface.
procedure, pass(this)	compute (this, time)
	Wrapper for calling compute_ based on the compute_controller. Serves as the public interface.
procedure(simulation_component_init), deferred, pass	init (this, json, case)
	The common constructor using a JSON dictionary.
procedure(simulation_component_free), deferred, pass	free (this)
	Destructor.
procedure, pass(this)	preprocess_ (this, time)
	The preprocessing function to be executed during the run.
procedure, pass(this)	compute_ (this, time)
	The main function to be executed during the run.
procedure, pass(this)	restart_ (this, time)
	The restart function to be called upon restarting simulation.
procedure, pass(this)	parse_json (this, json, case_params, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	JSON parameter parser for the time-based controllers.

Public Attributes
type(field_t), pointer	field => null()
	Field to sample.
type(coef_t), pointer	coef => null()
	Surface coefficients.
type(neumann_t)	bc
	Boundary mask built from the chosen zones.
integer, dimension(:), allocatable	zone_indices
	Labelled zones to include.
character(len=:), allocatable	field_name
	Name of the input field.
character(len=16), dimension(:), allocatable	operations
	Requested operations.
logical	compute_integral = .false.
	Whether to compute the integral.
logical	compute_average = .false.
	Whether to compute the average.
logical	compute_min = .false.
	Whether to compute the minimum.
logical	compute_max = .false.
	Whether to compute the maximum.
logical	log = .true.
	Whether to write results to the log.
logical	csv_output_enabled = .false.
	Whether CSV output is enabled.
type(file_t)	csv_output
	Optional CSV output file.
type(vector_t)	csv_row
	Reusable row buffer for CSV output.
type(vector_t)	areas
	Precomputed boundary quadrature weights.
type(vector_t)	surface_values
	Reusable gathered boundary values.
real(kind=rp)	integral = 0.0_rp
	Most recently computed integral.
real(kind=rp)	average = 0.0_rp
	Most recently computed average.
real(kind=rp)	minimum = huge(0.0_rp)
	Most recently computed minimum.
real(kind=rp)	maximum = -huge(0.0_rp)
	Most recently computed maximum.
type(case_t), pointer	case
	Pointer to the simulation case.
type(time_based_controller_t)	preprocess_controller
	Controller for when to run preprocess.
type(time_based_controller_t)	compute_controller
	Controller for when to run compute.
type(time_based_controller_t)	output_controller
	Controller for when to do output.
integer	order
	The execution order, lowest excutes first.
character(:), allocatable	name
	Unique name of the simcomp.

Private Member Functions
procedure, pass(this), private	init_common (this, name, coef, zone_indices, field_name, operations, log, output_filename)
	Common constructor used by all public constructors.

Detailed Description

Definition at line 58 of file boundary_operation.f90.

Member Function/Subroutine Documentation

compute()

procedure, pass(this) simulation_component::simulation_component_t::compute ( class(simulation_component_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	The current time.

Definition at line 91 of file simulation_component.f90.

compute_() [1/2]

procedure, pass(this) boundary_operation::boundary_operation_t::compute_	(	class(boundary_operation_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

time	Current simulation time state.

Definition at line 117 of file boundary_operation.f90.

compute_() [2/2]

procedure, pass(this) simulation_component::simulation_component_t::compute_ ( class(simulation_component_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	The current time.

Definition at line 99 of file simulation_component.f90.

free() [1/2]

procedure, pass(this) boundary_operation::boundary_operation_t::free

(

class(boundary_operation_t), intent(inout)

this

)

Definition at line 115 of file boundary_operation.f90.

free() [2/2]

procedure(simulation_component_free), deferred, pass simulation_component::simulation_component_t::free ( class(simulation_component_t), intent(inout)  this )

pure virtualinherited

Definition at line 95 of file simulation_component.f90.

free_base()

procedure, pass(this) simulation_component::simulation_component_t::free_base ( class(simulation_component_t), intent(inout)  this )

inherited

Definition at line 81 of file simulation_component.f90.

init() [1/2]

procedure, pass(this) boundary_operation::boundary_operation_t::init	(	class(boundary_operation_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

Parameters

json	JSON object describing the simcomp.
case	Simulation case.

Definition at line 101 of file boundary_operation.f90.

init() [2/2]

procedure(simulation_component_init), deferred, pass simulation_component::simulation_component_t::init ( class(simulation_component_t), intent(inout), target  this, type(json_file), intent(inout)  json, class(case_t), intent(inout), target  case  )

pure virtualinherited

Definition at line 93 of file simulation_component.f90.

init_base()

procedure, pass(this) simulation_component::simulation_component_t::init_base ( class(simulation_component_t), intent(inout)  this, type(json_file), intent(inout)  json, class(case_t), intent(inout), target  case  )

inherited

Definition at line 65 of file simulation_component.f90.

init_base_from_components() [1/2]

generic simulation_component::simulation_component_t::init_base_from_components ( class(simulation_component_t), intent(inout)  this, class(case_t), intent(inout), target  case, integer  order, character(len=*), intent(in)  preprocess_control, real(kind=rp), intent(in)  preprocess_value, character(len=*), intent(in)  compute_control, real(kind=rp), intent(in)  compute_value, character(len=*), intent(in)  output_control, real(kind=rp), intent(in)  output_value  )

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 67 of file simulation_component.f90.

init_base_from_components() [2/2]

generic simulation_component::simulation_component_t::init_base_from_components ( class(simulation_component_t), intent(inout)  this, class(case_t), intent(inout), target  case, integer  order, type(time_based_controller_t), intent(in)  preprocess_controller, type(time_based_controller_t), intent(in)  compute_controller, type(time_based_controller_t), intent(in)  output_controller  )

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 67 of file simulation_component.f90.

init_base_from_controllers()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers ( class(simulation_component_t), intent(inout)  this, class(case_t), intent(inout), target  case, integer  order, type(time_based_controller_t), intent(in)  preprocess_controller, type(time_based_controller_t), intent(in)  compute_controller, type(time_based_controller_t), intent(in)  output_controller  )

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 73 of file simulation_component.f90.

init_base_from_controllers_properties()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers_properties ( class(simulation_component_t), intent(inout)  this, class(case_t), intent(inout), target  case, integer  order, character(len=*), intent(in)  preprocess_control, real(kind=rp), intent(in)  preprocess_value, character(len=*), intent(in)  compute_control, real(kind=rp), intent(in)  compute_value, character(len=*), intent(in)  output_control, real(kind=rp), intent(in)  output_value  )

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 78 of file simulation_component.f90.

init_common()

procedure, pass(this), private boundary_operation::boundary_operation_t::init_common ( class(boundary_operation_t), intent(inout)  this, character(len=*), intent(in)  name, type(coef_t), intent(inout), target  coef, integer, dimension(:), intent(in)  zone_indices, character(len=*), intent(in)  field_name, character(len=*), dimension(:), intent(in)  operations, logical, intent(in)  log, character(len=*), intent(in), optional  output_filename  )

private

Parameters

name	Unique simcomp name.
coef	SEM coefficients.
zone_indices	Labelled zones to include.
field_name	Name of the registered field to process.
operations	Requested operations in output order.
log	Whether to emit tabular log output.
output_filename	Optional CSV output filename.

Definition at line 112 of file boundary_operation.f90.

init_from_components() [1/2]

generic boundary_operation::boundary_operation_t::init_from_components	(	class(boundary_operation_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), intent(in)	field_name,
		character(len=*), dimension(:), intent(in)	operations,
		logical, intent(in), optional	log,
		character(len=*), intent(in), optional	output_filename
	)

Parameters

name	Unique simcomp name.
case	Simulation case owning the simcomp.
order	Execution priority.
preprocess_control	Control mode for preprocessing.
preprocess_value	Control value for preprocessing.
compute_control	Control mode for computation.
compute_value	Control value for computation.
output_control	Control mode for output.
output_value	Control value for output.
zone_indices	Labelled zones to include.
field_name	Name of the registered field to process.
operations	Requested operations in output order.
log	Optional flag controlling log output.
output_filename	Optional CSV output filename.

Definition at line 103 of file boundary_operation.f90.

init_from_components() [2/2]

generic boundary_operation::boundary_operation_t::init_from_components	(	class(boundary_operation_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), intent(in)	field_name,
		character(len=*), dimension(:), intent(in)	operations,
		logical, intent(in), optional	log,
		character(len=*), intent(in), optional	output_filename
	)

Parameters

name	Unique simcomp name.
case	Simulation case owning the simcomp.
order	Execution priority.
preprocess_controller	Controller for preprocessing.
compute_controller	Controller for computation.
output_controller	Controller for output.
zone_indices	Labelled zones to include.
field_name	Name of the registered field to process.
operations	Requested operations in output order.
log	Optional flag controlling log output.
output_filename	Optional CSV output filename.

Definition at line 103 of file boundary_operation.f90.

init_from_controllers()

procedure, pass(this) boundary_operation::boundary_operation_t::init_from_controllers	(	class(boundary_operation_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), intent(in)	field_name,
		character(len=*), dimension(:), intent(in)	operations,
		logical, intent(in), optional	log,
		character(len=*), intent(in), optional	output_filename
	)

Parameters

name	Unique simcomp name.
case	Simulation case owning the simcomp.
order	Execution priority.
preprocess_controller	Controller for preprocessing.
compute_controller	Controller for computation.
output_controller	Controller for output.
zone_indices	Labelled zones to include.
field_name	Name of the registered field to process.
operations	Requested operations in output order.
log	Optional flag controlling log output.
output_filename	Optional CSV output filename.

Definition at line 106 of file boundary_operation.f90.

init_from_controllers_properties()

procedure, pass(this) boundary_operation::boundary_operation_t::init_from_controllers_properties	(	class(boundary_operation_t), intent(inout)	this,
		character(len=*), intent(in)	name,
		class(case_t), intent(inout), target	case,
		integer, intent(in)	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		integer, dimension(:), intent(in)	zone_indices,
		character(len=*), intent(in)	field_name,
		character(len=*), dimension(:), intent(in)	operations,
		logical, intent(in), optional	log,
		character(len=*), intent(in), optional	output_filename
	)

Parameters

name	Unique simcomp name.
case	Simulation case owning the simcomp.
order	Execution priority.
preprocess_control	Control mode for preprocessing.
preprocess_value	Control value for preprocessing.
compute_control	Control mode for computation.
compute_value	Control value for computation.
output_control	Control mode for output.
output_value	Control value for output.
zone_indices	Labelled zones to include.
field_name	Name of the registered field to process.
operations	Requested operations in output order.
log	Optional flag controlling log output.
output_filename	Optional CSV output filename.

Definition at line 109 of file boundary_operation.f90.

parse_json()

procedure, pass(this) simulation_component::simulation_component_t::parse_json ( class(simulation_component_t), intent(inout)  this, type(json_file), intent(inout)  json, type(json_file), intent(inout)  case_params, character(len=:), intent(inout), allocatable  preprocess_control, real(kind=rp), intent(out)  preprocess_value, character(len=:), intent(inout), allocatable  compute_control, real(kind=rp), intent(out)  compute_value, character(len=:), intent(inout), allocatable  output_control, real(kind=rp), intent(out)  output_value  )

inherited

Parameters

json	The JSON dictionary of the simcomp.
case_params	The entire case configuration JSON.
preprocess_value	Control mode for preprocessing.
preprocess_controller	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_controller	Value parameter for computing.
output_controller	Control mode for output.
output_controller	Value parameter for output.

Definition at line 103 of file simulation_component.f90.

preprocess()

procedure, pass(this) simulation_component::simulation_component_t::preprocess ( class(simulation_component_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	The current time.

Definition at line 87 of file simulation_component.f90.

preprocess_()

procedure, pass(this) simulation_component::simulation_component_t::preprocess_ ( class(simulation_component_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	The current time.

Definition at line 97 of file simulation_component.f90.

restart()

procedure, pass(this) simulation_component::simulation_component_t::restart ( class(simulation_component_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	The current time.

Definition at line 84 of file simulation_component.f90.

restart_()

procedure, pass(this) simulation_component::simulation_component_t::restart_ ( class(simulation_component_t), intent(inout)  this, type(time_state_t), intent(in)  time  )

inherited

Parameters

time	The current time.

Definition at line 101 of file simulation_component.f90.

Member Data Documentation

areas

type(vector_t) boundary_operation::boundary_operation_t::areas

Definition at line 88 of file boundary_operation.f90.

average

real(kind=rp) boundary_operation::boundary_operation_t::average = 0.0_rp

Definition at line 94 of file boundary_operation.f90.

bc

type(neumann_t) boundary_operation::boundary_operation_t::bc

Definition at line 64 of file boundary_operation.f90.

case

type(case_t), pointer simulation_component::simulation_component_t::case

inherited

Definition at line 52 of file simulation_component.f90.

coef

type(coef_t), pointer boundary_operation::boundary_operation_t::coef => null()

Definition at line 62 of file boundary_operation.f90.

compute_average

logical boundary_operation::boundary_operation_t::compute_average = .false.

Definition at line 74 of file boundary_operation.f90.

compute_controller

type(time_based_controller_t) simulation_component::simulation_component_t::compute_controller

inherited

Definition at line 56 of file simulation_component.f90.

compute_integral

logical boundary_operation::boundary_operation_t::compute_integral = .false.

Definition at line 72 of file boundary_operation.f90.

compute_max

logical boundary_operation::boundary_operation_t::compute_max = .false.

Definition at line 78 of file boundary_operation.f90.

compute_min

logical boundary_operation::boundary_operation_t::compute_min = .false.

Definition at line 76 of file boundary_operation.f90.

csv_output

type(file_t) boundary_operation::boundary_operation_t::csv_output

Definition at line 84 of file boundary_operation.f90.

csv_output_enabled

logical boundary_operation::boundary_operation_t::csv_output_enabled = .false.

Definition at line 82 of file boundary_operation.f90.

csv_row

type(vector_t) boundary_operation::boundary_operation_t::csv_row

Definition at line 86 of file boundary_operation.f90.

field

type(field_t), pointer boundary_operation::boundary_operation_t::field => null()

Definition at line 60 of file boundary_operation.f90.

field_name

character(len=:), allocatable boundary_operation::boundary_operation_t::field_name

Definition at line 68 of file boundary_operation.f90.

integral

real(kind=rp) boundary_operation::boundary_operation_t::integral = 0.0_rp

Definition at line 92 of file boundary_operation.f90.

log

logical boundary_operation::boundary_operation_t::log = .true.

Definition at line 80 of file boundary_operation.f90.

maximum

real(kind=rp) boundary_operation::boundary_operation_t::maximum = -huge(0.0_rp)

Definition at line 98 of file boundary_operation.f90.

minimum

real(kind=rp) boundary_operation::boundary_operation_t::minimum = huge(0.0_rp)

Definition at line 96 of file boundary_operation.f90.

name

character(:), allocatable simulation_component::simulation_component_t::name

inherited

Definition at line 62 of file simulation_component.f90.

operations

character(len=16), dimension(:), allocatable boundary_operation::boundary_operation_t::operations

Definition at line 70 of file boundary_operation.f90.

order

integer simulation_component::simulation_component_t::order

inherited

Definition at line 60 of file simulation_component.f90.

output_controller

type(time_based_controller_t) simulation_component::simulation_component_t::output_controller

inherited

Definition at line 58 of file simulation_component.f90.

preprocess_controller

type(time_based_controller_t) simulation_component::simulation_component_t::preprocess_controller

inherited

Definition at line 54 of file simulation_component.f90.

surface_values

type(vector_t) boundary_operation::boundary_operation_t::surface_values

Definition at line 90 of file boundary_operation.f90.

zone_indices

integer, dimension(:), allocatable boundary_operation::boundary_operation_t::zone_indices

Definition at line 66 of file boundary_operation.f90.

---

The documentation for this type was generated from the following file:

• /home/runner/work/neko/neko/src/simulation_components/boundary_operation.f90
