Inheritance diagram for fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t:

[legend]

Collaboration diagram for fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, msh, lx, params, user, chkp)
	Boundary condition factory for density.

procedure, pass(this)	free (this)
	Free allocated memory and cleanup.

procedure, pass(this)	step (this, time, dt_controller)
	Advance the fluid simulation one timestep.

procedure, pass(this)	restart (this, chkp)
	Restart the simulation from saved state.

procedure, pass(this)	setup_bcs (this, user, params)
	Set up boundary conditions.

procedure, pass(this)	scheme_init (this, msh, lx, params, scheme, user)
	Constructors.

procedure, pass(this)	scheme_free (this)
	Destructor for the base type.

procedure, pass(this)	validate (this)
	Validate that all components are properly allocated.

procedure(validate_intrf), deferred, pass	validate (this)
	Set the user inflow.

procedure, pass(this)	compute_cfl (this, dt)
	Compute the CFL number.

procedure(fluid_scheme_base_compute_cfl_intrf), deferred, pass	compute_cfl (this, dt)
	Compute the CFL number.

procedure, pass(this)	set_material_properties (this, params, user)
	Set rho and mu.

procedure, pass(this)	update_material_properties (this, time)
	Update variable material properties.

procedure(update_material_properties), deferred, pass	update_material_properties (this, time)
	Set rho and mu.

procedure, pass(this)	update_physical_flux (this)
	Refresh the physical-flux switches from the material properties.

procedure, pass(this)	compute_max_wave_speed (this)
	Compute maximum wave speed.

procedure, pass(this)	log_solver_info (this, params, scheme, lx)
	Log solver information.

procedure(fluid_scheme_base_init_intrf), deferred, pass	init (this, msh, lx, params, user, chkp)
	Constructor.

procedure(fluid_scheme_base_free_intrf), deferred, pass	free (this)
	Destructor.

procedure(fluid_scheme_base_step_intrf), deferred, pass	step (this, time, dt_controller)
	Advance one step in time.

procedure(fluid_scheme_base_restart_intrf), deferred, pass	restart (this, chkp)
	Restart from a checkpoint.

procedure(fluid_scheme_setup_bcs_intrf), deferred, pass	setup_bcs (this, user, params)

Public Attributes
type(field_t)	rho_res

type(field_t)	m_x_res

type(field_t)	m_y_res

type(field_t)	m_z_res

type(field_t)	m_e_res

type(field_t)	drho

type(field_t)	dm_x

type(field_t)	dm_y

type(field_t)	dm_z

type(field_t)	de

class(advection_t), allocatable	adv

class(ax_t), allocatable	ax

class(ax_t), allocatable	ax_stress

class(compressible_rhs_t), allocatable	compressible_rhs

type(runge_kutta_time_scheme_t)	rk_scheme

class(viscous_regularization_t), allocatable	viscous_regularization

logical	if_viscous_regularization

type(coupled_vector_bc_projector_t)	bcs_vel_projector
	Boundary conditions projector for velocity constraints.

type(bc_list_t)	bcs_density
	List of boundary conditions for density.

type(field_t), pointer	m_x => null()
	The momentum field.

type(field_t), pointer	m_y => null()
	y-component of Momentum

type(field_t), pointer	m_z => null()
	z-component of Momentum

type(field_t), pointer	e => null()
	Total energy.

type(field_t), pointer	temperature => null()
	Temperature field.

type(field_t), pointer	max_wave_speed => null()
	Maximum wave speed field.

type(field_t), pointer	artificial_visc => null()
	Artificial viscosity field (without physical)

type(field_t), pointer	kappa => null()
	Thermal conductivity.

real(kind=rp)	gamma

real(kind=rp)	mu_amax = 0.0_rp
	Largest magnitude of the dynamic viscosity over the domain.

real(kind=rp)	kappa_amax = 0.0_rp
	Largest magnitude of the thermal conductivity over the domain.

logical	add_physical_flux = .false.
	Whether the physical viscous and heat fluxes are evaluated.

logical	add_physical_stress = .false.
	Whether the physical viscous stress is evaluated.

logical	variable_material_properties = .false.
	Whether a user routine re-evaluates the material properties every time-step, in which case the switches above have to be refreshed.

integer(kind=i8)	glb_n_points
	Global number of GLL points for the fluid (not unique)

integer(kind=i8)	glb_unique_points
	Global number of GLL points for the fluid (unique)

character(len=:), allocatable	name
	A name that can be used to distinguish this solver in e.g. user routines.

type(space_t)	xh
	Function space \( X_h \).

type(dofmap_t)	dm_xh
	Dofmap associated with \( X_h \).

type(gs_t)	gs_xh
	Gather-scatter associated with \( X_h \).

type(coef_t)	c_xh
	Coefficients associated with \( X_h \).

type(time_scheme_controller_t), allocatable	ext_bdf

type(field_t), pointer	u => null()
	The velocity field.

type(field_t), pointer	v => null()
	y-component of Velocity

type(field_t), pointer	w => null()
	z-component of Velocity

type(field_t), pointer	p => null()
	Pressure.

type(field_series_t)	ulag

type(field_series_t)	vlag

type(field_series_t)	wlag
	fluid field (lag)

type(chkp_t), pointer	chkp => null()
	Checkpoint.

type(field_t), pointer	f_x => null()
	X-component of the right-hand side.

type(field_t), pointer	f_y => null()
	Y-component of the right-hand side.

type(field_t), pointer	f_z => null()
	Z-component of the right-hand side.

type(bc_list_t)	bcs_prs
	Boundary conditions.

type(bc_list_t)	bcs_vel

type(json_file), pointer	params
	Parameters.

type(mesh_t), pointer	msh => null()
	Mesh.

character(len=neko_msh_max_zlbl_len), dimension(:), allocatable	bc_labels
	Boundary condition labels (if any)

type(field_t), pointer	rho => null()
	Density field.

type(field_t), pointer	mu => null()
	The dynamic viscosity.

type(field_list_t)	material_properties
	A helper that packs material properties to pass to the user routine.

logical	freeze = .false.
	Is the fluid frozen at the moment.

Static Public Attributes
procedure(user_material_properties_intf), pointer, nopass	user_material_properties => null()
	User material properties routine.

Private Member Functions
procedure, pass, private	setup_viscous_regularization (this, params)

Detailed Description

Definition at line 80 of file fluid_scheme_compressible_ns.f90.

Member Function/Subroutine Documentation

◆ compute_cfl() [1/2]

procedure(fluid_scheme_base_compute_cfl_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::compute_cfl	(	class(fluid_scheme_base_t), intent(in)	this,
		real(kind=dp), intent(in)	dt
	)

pure virtualinherited

Definition at line 129 of file fluid_scheme_base.f90.

◆ compute_cfl() [2/2]

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::compute_cfl	(	class(fluid_scheme_compressible_t), intent(in)	this,
		real(kind=dp), intent(in)	dt
	)

inherited

Parameters

this	The compressible fluid scheme object
dt	Current timestep size

Returns: Computed CFL number

Definition at line 109 of file fluid_scheme_compressible.f90.

◆ compute_max_wave_speed()

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::compute_max_wave_speed ( class(fluid_scheme_compressible_t), intent(inout) this )

inherited

Parameters

this	The compressible fluid scheme object

Definition at line 121 of file fluid_scheme_compressible.f90.

◆ free() [1/2]

procedure(fluid_scheme_base_free_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::free ( class(fluid_scheme_base_t), intent(inout) this )

pure virtualinherited

Definition at line 118 of file fluid_scheme_base.f90.

◆ free() [2/2]

procedure, pass(this) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::free ( class(fluid_scheme_compressible_ns_t), intent(inout) this )

Parameters

this	The fluid scheme object to destroy

Definition at line 100 of file fluid_scheme_compressible_ns.f90.

◆ init() [1/2]

procedure(fluid_scheme_base_init_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::init	(	class(fluid_scheme_base_t), intent(inout), target	this,
		type(mesh_t), intent(inout), target	msh,
		integer, intent(in)	lx,
		type(json_file), intent(inout), target	params,
		type(user_t), intent(in), target	user,
		type(chkp_t), intent(inout), target	chkp
	)

pure virtualinherited

Definition at line 116 of file fluid_scheme_base.f90.

◆ init() [2/2]

procedure, pass(this) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::init	(	class(fluid_scheme_compressible_ns_t), intent(inout), target	this,
		type(mesh_t), intent(inout), target	msh,
		integer, intent(in)	lx,
		type(json_file), intent(inout), target	params,
		type(user_t), intent(in), target	user,
		type(chkp_t), intent(inout), target	chkp
	)

Will mark a mesh zone for the bc and finalize.

Parameters

[in,out]	object	The object to be allocated.
[in]	scheme	The `fluid_scheme_compressible_ns_t` scheme.
[in,out]	json	JSON object for initializing the bc.
[in]	coef	SEM coefficients.
[in]	user	The user interface. Boundary condition factory for pressure.

Will mark a mesh zone for the bc and finalize.

Parameters

[in,out]	object	The object to be allocated.
[in]	scheme	The `fluid_scheme_compressible_ns_t` scheme.
[in,out]	json	JSON object for initializing the bc.
[in]	coef	SEM coefficients.
[in]	user	The user interface. Boundary condition factory for velocity

Will mark a mesh zone for the bc and finalize.

Parameters

[in,out]	object	The object to be allocated.
[in]	scheme	The `fluid_scheme_compressible_ns_t` scheme.
[in,out]	json	JSON object for initializing the bc.
[in]	coef	SEM coefficients.
[in]	user	The user interface. Initialize the compressible Navier-Stokes fluid scheme
	this	The fluid scheme object
	msh	Mesh data structure
	lx	Polynomial order in x-direction
	params	JSON configuration parameters
	user	User-defined parameters and functions
	chkp	Checkpoint to write to

Definition at line 99 of file fluid_scheme_compressible_ns.f90.

◆ log_solver_info()

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::log_solver_info	(	class(fluid_scheme_compressible_t), intent(inout)	this,
		type(json_file), intent(inout)	params,
		character(len=*), intent(in)	scheme,
		integer, intent(in)	lx
	)

inherited

Parameters

this	The compressible fluid scheme object
params	JSON configuration parameters
scheme	Name of the numerical scheme
lx	Polynomial order in x-direction

Definition at line 124 of file fluid_scheme_compressible.f90.

◆ restart() [1/2]

procedure(fluid_scheme_base_restart_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::restart	(	class(fluid_scheme_base_t), intent(inout), target	this,
		type(chkp_t), intent(inout)	chkp
	)

pure virtualinherited

Definition at line 122 of file fluid_scheme_base.f90.

◆ restart() [2/2]

procedure, pass(this) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::restart	(	class(fluid_scheme_compressible_ns_t), intent(inout), target	this,
		type(chkp_t), intent(inout)	chkp
	)

Parameters

this	The fluid scheme object
dtlag	Previous timestep sizes
tlag	Previous time values

Definition at line 102 of file fluid_scheme_compressible_ns.f90.

◆ scheme_free()

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::scheme_free ( class(fluid_scheme_compressible_t), intent(inout) this )

inherited

Parameters

this	The compressible fluid scheme object to destroy

Definition at line 104 of file fluid_scheme_compressible.f90.

◆ scheme_init()

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::scheme_init	(	class(fluid_scheme_compressible_t), intent(inout), target	this,
		type(mesh_t), intent(inout), target	msh,
		integer, intent(in)	lx,
		type(json_file), intent(inout), target	params,
		character(len=*), intent(in)	scheme,
		type(user_t), intent(in), target	user
	)

inherited

Parameters

this	The compressible fluid scheme object
msh	Mesh data structure
lx	Polynomial order in x-direction
params	JSON configuration parameters
scheme	Name of the numerical scheme
user	User-defined parameters and functions

Definition at line 102 of file fluid_scheme_compressible.f90.

◆ set_material_properties()

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::set_material_properties	(	class(fluid_scheme_compressible_t), intent(inout), target	this,
		type(json_file), intent(inout)	params,
		type(user_t), intent(in), target	user
	)

inherited

Parameters

this	The compressible fluid scheme object
params	The case parameter file
user	The user interface

Definition at line 112 of file fluid_scheme_compressible.f90.

◆ setup_bcs() [1/2]

procedure(fluid_scheme_setup_bcs_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::setup_bcs	(	class(fluid_scheme_base_t), intent(inout), target	this,
		type(user_t), intent(in), target	user,
		type(json_file), intent(inout)	params
	)

pure virtualinherited

Definition at line 124 of file fluid_scheme_base.f90.

◆ setup_bcs() [2/2]

procedure, pass(this) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::setup_bcs	(	class(fluid_scheme_compressible_ns_t), intent(inout), target	this,
		type(user_t), intent(in), target	user,
		type(json_file), intent(inout)	params
	)

Parameters

this	The fluid scheme object
user	User-defined boundary conditions
params	Configuration parameters

Definition at line 104 of file fluid_scheme_compressible_ns.f90.

◆ setup_viscous_regularization()

procedure, pass, private fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::setup_viscous_regularization	(	class(fluid_scheme_compressible_ns_t), intent(inout), target	this,
		type(json_file), intent(inout)	params
	)

private

Definition at line 106 of file fluid_scheme_compressible_ns.f90.

◆ step() [1/2]

procedure(fluid_scheme_base_step_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::step	(	class(fluid_scheme_base_t), intent(inout), target	this,
		type(time_state_t), intent(in)	time,
		type(time_step_controller_t), intent(in)	dt_controller
	)

pure virtualinherited

Definition at line 120 of file fluid_scheme_base.f90.

◆ step() [2/2]

procedure, pass(this) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::step	(	class(fluid_scheme_compressible_ns_t), intent(inout), target	this,
		type(time_state_t), intent(in)	time,
		type(time_step_controller_t), intent(in)	dt_controller
	)

Parameters

this	The fluid scheme object
time	Current simulation time state
ext_bdf	Time integration controller
dt_controller	Timestep size controller

Definition at line 101 of file fluid_scheme_compressible_ns.f90.

◆ update_material_properties() [1/2]

procedure(update_material_properties), deferred, pass fluid_scheme_base::fluid_scheme_base_t::update_material_properties	(	class(fluid_scheme_base_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

pure virtualinherited

Definition at line 132 of file fluid_scheme_base.f90.

◆ update_material_properties() [2/2]

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::update_material_properties	(	class(fluid_scheme_compressible_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

this	The compressible fluid scheme object
time	The time state

Definition at line 115 of file fluid_scheme_compressible.f90.

◆ update_physical_flux()

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::update_physical_flux ( class(fluid_scheme_compressible_t), intent(inout) this )

inherited

Decides whether the physical Navier-Stokes viscous and heat fluxes have to be evaluated at all, by testing \( \max_i |\mu_i| \) and \( \max_i |\kappa_i| \) against zero.

On a device backend the reduction runs as a kernel over the device resident arrays. Inspecting the host mirrors mux and kappax instead would be wrong as well as slow: field_cfill, and the device_math routines a user file calls, only write x_d, so the host copies stay at their initial zero and the solver would silently degrade to Euler.

The reduction is global, so all ranks agree on the branch taken even when the viscosity is non-zero on only some of them.

Parameters

this	The compressible fluid scheme object

Definition at line 118 of file fluid_scheme_compressible.f90.

◆ validate() [1/2]

procedure(validate_intrf), deferred, pass fluid_scheme_base::fluid_scheme_base_t::validate ( class(fluid_scheme_base_t), intent(inout), target this )

pure virtualinherited

Definition at line 127 of file fluid_scheme_base.f90.

◆ validate() [2/2]

procedure, pass(this) fluid_scheme_compressible::fluid_scheme_compressible_t::validate ( class(fluid_scheme_compressible_t), intent(inout), target this )

inherited

Parameters

this	The compressible fluid scheme object

Definition at line 107 of file fluid_scheme_compressible.f90.

Member Data Documentation

◆ add_physical_flux

logical fluid_scheme_compressible::fluid_scheme_compressible_t::add_physical_flux = .false.

inherited

Definition at line 88 of file fluid_scheme_compressible.f90.

◆ add_physical_stress

logical fluid_scheme_compressible::fluid_scheme_compressible_t::add_physical_stress = .false.

inherited

Definition at line 90 of file fluid_scheme_compressible.f90.

◆ adv

class(advection_t), allocatable fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::adv

Definition at line 84 of file fluid_scheme_compressible_ns.f90.

◆ artificial_visc

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::artificial_visc => null()

inherited

Definition at line 77 of file fluid_scheme_compressible.f90.

◆ ax

class(ax_t), allocatable fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::ax

Definition at line 85 of file fluid_scheme_compressible_ns.f90.

◆ ax_stress

class(ax_t), allocatable fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::ax_stress

Definition at line 86 of file fluid_scheme_compressible_ns.f90.

◆ bc_labels

character(len=neko_msh_max_zlbl_len), dimension(:), allocatable fluid_scheme_base::fluid_scheme_base_t::bc_labels

inherited

Definition at line 96 of file fluid_scheme_base.f90.

◆ bcs_density

type(bc_list_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::bcs_density

Definition at line 96 of file fluid_scheme_compressible_ns.f90.

◆ bcs_prs

type(bc_list_t) fluid_scheme_base::fluid_scheme_base_t::bcs_prs

inherited

Definition at line 88 of file fluid_scheme_base.f90.

◆ bcs_vel

type(bc_list_t) fluid_scheme_base::fluid_scheme_base_t::bcs_vel

inherited

Definition at line 90 of file fluid_scheme_base.f90.

◆ bcs_vel_projector

type(coupled_vector_bc_projector_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::bcs_vel_projector

Definition at line 94 of file fluid_scheme_compressible_ns.f90.

◆ c_xh

type(coef_t) fluid_scheme_base::fluid_scheme_base_t::c_xh

inherited

Definition at line 65 of file fluid_scheme_base.f90.

◆ chkp

type(chkp_t), pointer fluid_scheme_base::fluid_scheme_base_t::chkp => null()

inherited

Definition at line 77 of file fluid_scheme_base.f90.

◆ compressible_rhs

class(compressible_rhs_t), allocatable fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::compressible_rhs

Definition at line 87 of file fluid_scheme_compressible_ns.f90.

◆ de

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::de

Definition at line 83 of file fluid_scheme_compressible_ns.f90.

◆ dm_x

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::dm_x

Definition at line 83 of file fluid_scheme_compressible_ns.f90.

◆ dm_xh

type(dofmap_t) fluid_scheme_base::fluid_scheme_base_t::dm_xh

inherited

Definition at line 63 of file fluid_scheme_base.f90.

◆ dm_y

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::dm_y

Definition at line 83 of file fluid_scheme_compressible_ns.f90.

◆ dm_z

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::dm_z

Definition at line 83 of file fluid_scheme_compressible_ns.f90.

◆ drho

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::drho

Definition at line 83 of file fluid_scheme_compressible_ns.f90.

◆ e

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::e => null()

inherited

Definition at line 74 of file fluid_scheme_compressible.f90.

◆ ext_bdf

type(time_scheme_controller_t), allocatable fluid_scheme_base::fluid_scheme_base_t::ext_bdf

inherited

Definition at line 67 of file fluid_scheme_base.f90.

◆ f_x

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::f_x => null()

inherited

Definition at line 80 of file fluid_scheme_base.f90.

◆ f_y

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::f_y => null()

inherited

Definition at line 82 of file fluid_scheme_base.f90.

◆ f_z

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::f_z => null()

inherited

Definition at line 84 of file fluid_scheme_base.f90.

◆ freeze

logical fluid_scheme_base::fluid_scheme_base_t::freeze = .false.

inherited

Definition at line 108 of file fluid_scheme_base.f90.

◆ gamma

real(kind=rp) fluid_scheme_compressible::fluid_scheme_compressible_t::gamma

inherited

Definition at line 80 of file fluid_scheme_compressible.f90.

◆ glb_n_points

integer(kind=i8) fluid_scheme_compressible::fluid_scheme_compressible_t::glb_n_points

inherited

Definition at line 96 of file fluid_scheme_compressible.f90.

◆ glb_unique_points

integer(kind=i8) fluid_scheme_compressible::fluid_scheme_compressible_t::glb_unique_points

inherited

Definition at line 98 of file fluid_scheme_compressible.f90.

◆ gs_xh

type(gs_t) fluid_scheme_base::fluid_scheme_base_t::gs_xh

inherited

Definition at line 64 of file fluid_scheme_base.f90.

◆ if_viscous_regularization

logical fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::if_viscous_regularization

Definition at line 91 of file fluid_scheme_compressible_ns.f90.

◆ kappa

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::kappa => null()

inherited

Definition at line 78 of file fluid_scheme_compressible.f90.

◆ kappa_amax

real(kind=rp) fluid_scheme_compressible::fluid_scheme_compressible_t::kappa_amax = 0.0_rp

inherited

Definition at line 85 of file fluid_scheme_compressible.f90.

◆ m_e_res

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::m_e_res

Definition at line 82 of file fluid_scheme_compressible_ns.f90.

◆ m_x

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::m_x => null()

inherited

x-component of Momentum

Definition at line 71 of file fluid_scheme_compressible.f90.

◆ m_x_res

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::m_x_res

Definition at line 82 of file fluid_scheme_compressible_ns.f90.

◆ m_y

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::m_y => null()

inherited

Definition at line 72 of file fluid_scheme_compressible.f90.

◆ m_y_res

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::m_y_res

Definition at line 82 of file fluid_scheme_compressible_ns.f90.

◆ m_z

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::m_z => null()

inherited

Definition at line 73 of file fluid_scheme_compressible.f90.

◆ m_z_res

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::m_z_res

Definition at line 82 of file fluid_scheme_compressible_ns.f90.

◆ material_properties

type(field_list_t) fluid_scheme_base::fluid_scheme_base_t::material_properties

inherited

Definition at line 105 of file fluid_scheme_base.f90.

◆ max_wave_speed

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::max_wave_speed => null()

inherited

Definition at line 76 of file fluid_scheme_compressible.f90.

◆ msh

type(mesh_t), pointer fluid_scheme_base::fluid_scheme_base_t::msh => null()

inherited

Definition at line 93 of file fluid_scheme_base.f90.

◆ mu

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::mu => null()

inherited

Definition at line 102 of file fluid_scheme_base.f90.

◆ mu_amax

real(kind=rp) fluid_scheme_compressible::fluid_scheme_compressible_t::mu_amax = 0.0_rp

inherited

Definition at line 83 of file fluid_scheme_compressible.f90.

◆ name

character(len=:), allocatable fluid_scheme_base::fluid_scheme_base_t::name

inherited

Definition at line 60 of file fluid_scheme_base.f90.

◆ p

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::p => null()

inherited

Definition at line 73 of file fluid_scheme_base.f90.

◆ params

type(json_file), pointer fluid_scheme_base::fluid_scheme_base_t::params

inherited

Definition at line 92 of file fluid_scheme_base.f90.

◆ rho

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::rho => null()

inherited

Definition at line 99 of file fluid_scheme_base.f90.

◆ rho_res

type(field_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::rho_res

Definition at line 82 of file fluid_scheme_compressible_ns.f90.

◆ rk_scheme

type(runge_kutta_time_scheme_t) fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::rk_scheme

Definition at line 88 of file fluid_scheme_compressible_ns.f90.

◆ temperature

type(field_t), pointer fluid_scheme_compressible::fluid_scheme_compressible_t::temperature => null()

inherited

Definition at line 75 of file fluid_scheme_compressible.f90.

◆ u

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::u => null()

inherited

x-component of Velocity

Definition at line 70 of file fluid_scheme_base.f90.

◆ ulag

type(field_series_t) fluid_scheme_base::fluid_scheme_base_t::ulag

inherited

Definition at line 74 of file fluid_scheme_base.f90.

◆ user_material_properties

procedure(user_material_properties_intf), pointer, nopass fluid_scheme_base::fluid_scheme_base_t::user_material_properties => null()

staticinherited

Definition at line 111 of file fluid_scheme_base.f90.

◆ v

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::v => null()

inherited

Definition at line 71 of file fluid_scheme_base.f90.

◆ variable_material_properties

logical fluid_scheme_compressible::fluid_scheme_compressible_t::variable_material_properties = .false.

inherited

Definition at line 93 of file fluid_scheme_compressible.f90.

◆ viscous_regularization

class(viscous_regularization_t), allocatable fluid_scheme_compressible_ns::fluid_scheme_compressible_ns_t::viscous_regularization

Definition at line 90 of file fluid_scheme_compressible_ns.f90.

◆ vlag

type(field_series_t) fluid_scheme_base::fluid_scheme_base_t::vlag

inherited

Definition at line 74 of file fluid_scheme_base.f90.

◆ w

type(field_t), pointer fluid_scheme_base::fluid_scheme_base_t::w => null()

inherited

Definition at line 72 of file fluid_scheme_base.f90.

◆ wlag

type(field_series_t) fluid_scheme_base::fluid_scheme_base_t::wlag

inherited

Definition at line 74 of file fluid_scheme_base.f90.

◆ xh

type(space_t) fluid_scheme_base::fluid_scheme_base_t::xh

inherited

Definition at line 62 of file fluid_scheme_base.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/fluid/fluid_scheme_compressible_ns.f90

Public Member Functions

Public Attributes

Static Public Attributes

Private Member Functions

Detailed Description

Member Function/Subroutine Documentation

◆ compute_cfl() [1/2]

◆ compute_cfl() [2/2]

◆ compute_max_wave_speed()

◆ free() [1/2]

◆ free() [2/2]

◆ init() [1/2]

◆ init() [2/2]

◆ log_solver_info()

◆ restart() [1/2]

◆ restart() [2/2]

◆ scheme_free()

◆ scheme_init()

◆ set_material_properties()

◆ setup_bcs() [1/2]

◆ setup_bcs() [2/2]

◆ setup_viscous_regularization()

◆ step() [1/2]

◆ step() [2/2]

◆ update_material_properties() [1/2]

◆ update_material_properties() [2/2]

◆ update_physical_flux()

◆ validate() [1/2]

◆ validate() [2/2]

Member Data Documentation

◆ add_physical_flux

◆ add_physical_stress

◆ adv

◆ artificial_visc

◆ ax

◆ ax_stress

◆ bc_labels

◆ bcs_density

◆ bcs_prs

◆ bcs_vel

◆ bcs_vel_projector

◆ c_xh

◆ chkp

◆ compressible_rhs

◆ de

◆ dm_x

◆ dm_xh

◆ dm_y

◆ dm_z

◆ drho

◆ e

◆ ext_bdf

◆ f_x

◆ f_y

◆ f_z

◆ freeze

◆ gamma

◆ glb_n_points

◆ glb_unique_points

◆ gs_xh

◆ if_viscous_regularization

◆ kappa

◆ kappa_amax

◆ m_e_res

◆ m_x

◆ m_x_res

◆ m_y

◆ m_y_res

◆ m_z

◆ m_z_res

◆ material_properties

◆ max_wave_speed

◆ msh

◆ mu

◆ mu_amax

◆ name

◆ p

◆ params

◆ rho

◆ rho_res
