A simulation component that computes the force and torque on a given boundary zone. More...

Inheritance diagram for force_torque::force_torque_t:

Collaboration diagram for force_torque::force_torque_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, json, case)
	Constructor from json, wrapping the actual constructor.

generic	init_from_components (this, case, order, preprocess_controller, compute_controller, output_controller, fluid_name, zone_id, zone_name, center, scale, coef, long_print)
	Generic for constructing from components.

generic	init_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, fluid_name, zone_name, zone_id, center, scale, coef, long_print)
	Generic for constructing from components.

procedure, pass(this)	init_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller, fluid_name, zone_id, zone_name, center, scale, coef, long_print)
	Constructor from components, passing time_based_controllers.

procedure, pass(this)	init_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, fluid_name, zone_name, zone_id, center, scale, coef, long_print)
	Constructor from components, passing the properties of time_based_controllers.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	compute_ (this, time)
	Compute the force_torque field.

procedure, pass(this)	init_base (this, json, case)
	Constructor for the simulation_component_t (base) class.

generic	init_base_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from components.

generic	init_base_from_components (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from components.

procedure, pass(this)	init_base_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from time_based_controllers, essentially directly from all components (we reserve the `_from_components` name for the generic binding).

procedure, pass(this)	init_base_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from properties of time_based_controllers, so the latter are constructed instead of assigned.

procedure, pass(this)	free_base (this)
	Destructor for the simulation_component_t (base) class.

procedure, pass(this)	restart (this, time)
	Wrapper for calling `set_counter` for the time based controllers. Serves as the public interface.

procedure, pass(this)	preprocess (this, time)
	Wrapper for calling `preprocess_` based on the `preprocess_controller`. Serves as the public interface.

procedure, pass(this)	compute (this, time)
	Wrapper for calling `compute_` based on the `compute_controller`. Serves as the public interface.

procedure(simulation_component_init), deferred, pass	init (this, json, case)
	The common constructor using a JSON dictionary.

procedure(simulation_component_free), deferred, pass	free (this)
	Destructor.

procedure, pass(this)	preprocess_ (this, time)
	The preprocessing function to be executed during the run.

procedure, pass(this)	compute_ (this, time)
	The main function to be executed during the run.

procedure, pass(this)	restart_ (this, time)
	The restart function to be called upon restarting simulation.

procedure, pass(this)	parse_json (this, json, case_params, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	JSON parameter parser for the time-based controllers.

Public Attributes
type(field_t), pointer	u => null()
	X velocity component.

type(field_t), pointer	v => null()
	Y velocity component.

type(field_t), pointer	w => null()
	Z velocity component.

type(field_t), pointer	p => null()
	Pressure.

type(field_t), pointer	mu => null()
	Total dynamic viscosity.

type(vector_t)	n1

type(vector_t)	n2

type(vector_t)	n3

type(vector_t)	r1

type(vector_t)	r2

type(vector_t)	r3

type(vector_t)	force1

type(vector_t)	force2

type(vector_t)	force3

type(vector_t)	force4

type(vector_t)	force5

type(vector_t)	force6

type(vector_t)	pmsk

type(vector_t)	mu_msk

type(vector_t)	s11msk

type(vector_t)	s22msk

type(vector_t)	s33msk

type(vector_t)	s12msk

type(vector_t)	s13msk

type(vector_t)	s23msk

real(kind=rp), dimension(3)	center = 0.0_rp

real(kind=rp)	scale

integer	zone_id

character(len=20)	zone_name

type(coef_t), pointer	coef => null()

type(dirichlet_t)	bc

character(len=80)	print_format

type(case_t), pointer	case
	Pointer to the simulation case.

type(time_based_controller_t)	preprocess_controller
	Controller for when to run `preprocess`.

type(time_based_controller_t)	compute_controller
	Controller for when to run `compute`.

type(time_based_controller_t)	output_controller
	Controller for when to do output.

integer	order
	The execution order, lowest excutes first.

Private Member Functions
procedure, pass(this), private	init_common (this, fluid_name, zone_id, zone_name, center, scale, coef, long_print)
	Common part of constructors.

Detailed Description

Definition at line 68 of file force_torque.f90.

Member Function/Subroutine Documentation

◆ compute()

procedure, pass(this) simulation_component::simulation_component_t::compute	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 88 of file simulation_component.f90.

◆ compute_() [1/2]

procedure, pass(this) force_torque::force_torque_t::compute_	(	class(force_torque_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

time	The current time state.

Definition at line 114 of file force_torque.f90.

◆ compute_() [2/2]

procedure, pass(this) simulation_component::simulation_component_t::compute_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 96 of file simulation_component.f90.

◆ free() [1/2]

procedure, pass(this) force_torque::force_torque_t::free ( class(force_torque_t), intent(inout) this )

Definition at line 112 of file force_torque.f90.

◆ free() [2/2]

procedure(simulation_component_free), deferred, pass simulation_component::simulation_component_t::free ( class(simulation_component_t), intent(inout) this )

pure virtualinherited

Definition at line 92 of file simulation_component.f90.

◆ free_base()

procedure, pass(this) simulation_component::simulation_component_t::free_base ( class(simulation_component_t), intent(inout) this )

inherited

Definition at line 78 of file simulation_component.f90.

◆ init() [1/2]

procedure, pass(this) force_torque::force_torque_t::init	(	class(force_torque_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

Definition at line 98 of file force_torque.f90.

◆ init() [2/2]

procedure(simulation_component_init), deferred, pass simulation_component::simulation_component_t::init	(	class(simulation_component_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

pure virtualinherited

Definition at line 90 of file simulation_component.f90.

◆ init_base()

procedure, pass(this) simulation_component::simulation_component_t::init_base	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

inherited

Definition at line 62 of file simulation_component.f90.

◆ init_base_from_components() [1/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 64 of file simulation_component.f90.

◆ init_base_from_components() [2/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 64 of file simulation_component.f90.

◆ init_base_from_controllers()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 70 of file simulation_component.f90.

◆ init_base_from_controllers_properties()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers_properties	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 75 of file simulation_component.f90.

◆ init_common()

procedure, pass(this), private force_torque::force_torque_t::init_common	(	class(force_torque_t), intent(inout)	this,
		character(len=*), intent(in)	fluid_name,
		integer, intent(in)	zone_id,
		character(len=*), intent(in)	zone_name,
		real(kind=rp), dimension(3), intent(in)	center,
		real(kind=rp), intent(in)	scale,
		type(coef_t), intent(in), target	coef,
		logical, intent(in)	long_print
	)

private

Parameters

fluid_name	The name of the fluid solver.
zone_id	The id of the boundary zone.
zone_name	The name of the boundary zone, to use in the log.
center	The center of the torque calculation.
scale	Normalization factor.
coef	The SEM coefficients.
long_print	If true, use a more precise print format.

Definition at line 100 of file force_torque.f90.

◆ init_from_components() [1/2]

generic force_torque::force_torque_t::init_from_components	(	class(force_torque_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*), intent(in)	fluid_name,
		character(len=*), intent(in)	zone_name,
		integer, intent(in)	zone_id,
		real(kind=rp), dimension(3), intent(in)	center,
		real(kind=rp), intent(in)	scale,
		type(coef_t), intent(in), target	coef,
		logical, intent(in)	long_print
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
fluid_name	The name of the fluid solver.
zone_id	The id of the boundary zone.
zone_name	The name of the boundary zone, to use in the log.
center	The center of the torque calculation.
scale	Normalization factor.
coef	The SEM coefficients.
long_print	If true, use a more precise print format.

Definition at line 102 of file force_torque.f90.

◆ init_from_components() [2/2]

generic force_torque::force_torque_t::init_from_components	(	class(force_torque_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*), intent(in)	fluid_name,
		integer, intent(in)	zone_id,
		character(len=*), intent(in)	zone_name,
		real(kind=rp), dimension(3), intent(in)	center,
		real(kind=rp), intent(in)	scale,
		type(coef_t), intent(in), target	coef,
		logical, intent(in)	long_print
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
fluid_name	The name of the fluid solver.
zone_id	The id of the boundary zone.
zone_name	The name of the boundary zone, to use in the log.
center	The center of the torque calculation.
scale	Normalization factor.
coef	The SEM coefficients.
long_print	If true, use a more precise print format.

Definition at line 102 of file force_torque.f90.

◆ init_from_controllers()

procedure, pass(this) force_torque::force_torque_t::init_from_controllers	(	class(force_torque_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		character(len=*), intent(in)	fluid_name,
		integer, intent(in)	zone_id,
		character(len=*), intent(in)	zone_name,
		real(kind=rp), dimension(3), intent(in)	center,
		real(kind=rp), intent(in)	scale,
		type(coef_t), intent(in), target	coef,
		logical, intent(in)	long_print
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
fluid_name	The name of the fluid solver.
zone_id	The id of the boundary zone.
zone_name	The name of the boundary zone, to use in the log.
center	The center of the torque calculation.
scale	Normalization factor.
coef	The SEM coefficients.
long_print	If true, use a more precise print format.

Definition at line 105 of file force_torque.f90.

◆ init_from_controllers_properties()

procedure, pass(this) force_torque::force_torque_t::init_from_controllers_properties	(	class(force_torque_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		character(len=*), intent(in)	fluid_name,
		character(len=*), intent(in)	zone_name,
		integer, intent(in)	zone_id,
		real(kind=rp), dimension(3), intent(in)	center,
		real(kind=rp), intent(in)	scale,
		type(coef_t), intent(in), target	coef,
		logical, intent(in)	long_print
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
fluid_name	The name of the fluid solver.
zone_id	The id of the boundary zone.
zone_name	The name of the boundary zone, to use in the log.
center	The center of the torque calculation.
scale	Normalization factor.
coef	The SEM coefficients.
long_print	If true, use a more precise print format.

Definition at line 109 of file force_torque.f90.

◆ parse_json()

procedure, pass(this) simulation_component::simulation_component_t::parse_json	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(json_file), intent(inout)	case_params,
		character(len=:), intent(inout), allocatable	preprocess_control,
		real(kind=rp), intent(out)	preprocess_value,
		character(len=:), intent(inout), allocatable	compute_control,
		real(kind=rp), intent(out)	compute_value,
		character(len=:), intent(inout), allocatable	output_control,
		real(kind=rp), intent(out)	output_value
	)

inherited

Parameters

json	The JSON dictionary of the simcomp.
case_params	The entire case configuration JSON.
preprocess_value	Control mode for preprocessing.
preprocess_controller	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_controller	Value parameter for computing.
output_controller	Control mode for output.
output_controller	Value parameter for output.

Definition at line 100 of file simulation_component.f90.

◆ preprocess()

procedure, pass(this) simulation_component::simulation_component_t::preprocess	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 84 of file simulation_component.f90.

◆ preprocess_()

procedure, pass(this) simulation_component::simulation_component_t::preprocess_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 94 of file simulation_component.f90.

◆ restart()

procedure, pass(this) simulation_component::simulation_component_t::restart	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 81 of file simulation_component.f90.

◆ restart_()

procedure, pass(this) simulation_component::simulation_component_t::restart_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 98 of file simulation_component.f90.

Member Data Documentation

◆ bc

type(dirichlet_t) force_torque::force_torque_t::bc

Definition at line 93 of file force_torque.f90.

◆ case

type(case_t), pointer simulation_component::simulation_component_t::case

inherited

Definition at line 51 of file simulation_component.f90.

◆ center

real(kind=rp), dimension(3) force_torque::force_torque_t::center = 0.0_rp

Definition at line 88 of file force_torque.f90.

◆ coef

type(coef_t), pointer force_torque::force_torque_t::coef => null()

Definition at line 92 of file force_torque.f90.

◆ compute_controller

type(time_based_controller_t) simulation_component::simulation_component_t::compute_controller

inherited

Definition at line 55 of file simulation_component.f90.

◆ force1

type(vector_t) force_torque::force_torque_t::force1

Definition at line 83 of file force_torque.f90.

◆ force2

type(vector_t) force_torque::force_torque_t::force2

Definition at line 83 of file force_torque.f90.

◆ force3

type(vector_t) force_torque::force_torque_t::force3

Definition at line 83 of file force_torque.f90.

◆ force4

type(vector_t) force_torque::force_torque_t::force4

Definition at line 84 of file force_torque.f90.

◆ force5

type(vector_t) force_torque::force_torque_t::force5

Definition at line 84 of file force_torque.f90.

◆ force6

type(vector_t) force_torque::force_torque_t::force6

Definition at line 84 of file force_torque.f90.

◆ mu

type(field_t), pointer force_torque::force_torque_t::mu => null()

Definition at line 78 of file force_torque.f90.

◆ mu_msk

type(vector_t) force_torque::force_torque_t::mu_msk

Definition at line 86 of file force_torque.f90.

◆ n1

type(vector_t) force_torque::force_torque_t::n1

Definition at line 81 of file force_torque.f90.

◆ n2

type(vector_t) force_torque::force_torque_t::n2

Definition at line 81 of file force_torque.f90.

◆ n3

type(vector_t) force_torque::force_torque_t::n3

Definition at line 81 of file force_torque.f90.

◆ order

integer simulation_component::simulation_component_t::order

inherited

Definition at line 59 of file simulation_component.f90.

◆ output_controller

type(time_based_controller_t) simulation_component::simulation_component_t::output_controller

inherited

Definition at line 57 of file simulation_component.f90.

◆ p

type(field_t), pointer force_torque::force_torque_t::p => null()

Definition at line 76 of file force_torque.f90.

◆ pmsk

type(vector_t) force_torque::force_torque_t::pmsk

Definition at line 85 of file force_torque.f90.

◆ preprocess_controller

type(time_based_controller_t) simulation_component::simulation_component_t::preprocess_controller

inherited

Definition at line 53 of file simulation_component.f90.

◆ print_format

character(len=80) force_torque::force_torque_t::print_format

Definition at line 94 of file force_torque.f90.

◆ r1

type(vector_t) force_torque::force_torque_t::r1

Definition at line 82 of file force_torque.f90.

◆ r2

type(vector_t) force_torque::force_torque_t::r2

Definition at line 82 of file force_torque.f90.

◆ r3

type(vector_t) force_torque::force_torque_t::r3

Definition at line 82 of file force_torque.f90.

◆ s11msk

type(vector_t) force_torque::force_torque_t::s11msk

Definition at line 87 of file force_torque.f90.

◆ s12msk

type(vector_t) force_torque::force_torque_t::s12msk

Definition at line 87 of file force_torque.f90.

◆ s13msk

type(vector_t) force_torque::force_torque_t::s13msk

Definition at line 87 of file force_torque.f90.

◆ s22msk

type(vector_t) force_torque::force_torque_t::s22msk

Definition at line 87 of file force_torque.f90.

◆ s23msk

type(vector_t) force_torque::force_torque_t::s23msk

Definition at line 87 of file force_torque.f90.

◆ s33msk

type(vector_t) force_torque::force_torque_t::s33msk

Definition at line 87 of file force_torque.f90.

◆ scale

real(kind=rp) force_torque::force_torque_t::scale

Definition at line 89 of file force_torque.f90.

◆ u

type(field_t), pointer force_torque::force_torque_t::u => null()

Definition at line 70 of file force_torque.f90.

◆ v

type(field_t), pointer force_torque::force_torque_t::v => null()

Definition at line 72 of file force_torque.f90.

◆ w

type(field_t), pointer force_torque::force_torque_t::w => null()

Definition at line 74 of file force_torque.f90.

◆ zone_id

integer force_torque::force_torque_t::zone_id

Definition at line 90 of file force_torque.f90.

◆ zone_name

character(len=20) force_torque::force_torque_t::zone_name

Definition at line 91 of file force_torque.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/simulation_components/force_torque.f90

Public Member Functions

Public Attributes

Private Member Functions

Detailed Description

Member Function/Subroutine Documentation

◆ compute()

◆ compute_() [1/2]

◆ compute_() [2/2]

◆ free() [1/2]

◆ free() [2/2]

◆ free_base()

◆ init() [1/2]

◆ init() [2/2]

◆ init_base()

◆ init_base_from_components() [1/2]

◆ init_base_from_components() [2/2]

◆ init_base_from_controllers()

◆ init_base_from_controllers_properties()

◆ init_common()

◆ init_from_components() [1/2]

◆ init_from_components() [2/2]

◆ init_from_controllers()

◆ init_from_controllers_properties()

◆ parse_json()

◆ preprocess()

◆ preprocess_()

◆ restart()

◆ restart_()

Member Data Documentation

◆ bc

◆ case

◆ center

◆ coef

◆ compute_controller

◆ force1

◆ force2

◆ force3

◆ force4

◆ force5

◆ force6

◆ mu

◆ mu_msk

◆ n1

◆ n2

◆ n3

◆ order

◆ output_controller

◆ p

◆ pmsk

◆ preprocess_controller

◆ print_format

◆ r1

◆ r2

◆ r3

◆ s11msk

◆ s12msk

◆ s13msk

◆ s22msk

◆ s23msk

◆ s33msk

◆ scale

◆ u

◆ v

◆ w

◆ zone_id

◆ zone_name
