A simulation component that computes the averages of fields in the registry. More...

Inheritance diagram for user_stats::user_stats_t:

Collaboration diagram for user_stats::user_stats_t:

[legend]

Public Member Functions
procedure, pass(this)	init (this, json, case)
	Constructor from json, wrapping the actual constructor.

generic	init_from_components (this, case, order, preprocess_controller, compute_controller, output_controller, start_time, coef, avg_dir, filename, precision)
	Generic for constructing from components.

generic	init_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, start_time, coef, avg_dir, filename, precision)
	Generic for constructing from components.

procedure, pass(this)	init_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller, start_time, coef, avg_dir, filename, precision)
	Constructor from components, passing time_based_controllers.

procedure, pass(this)	init_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value, start_time, coef, avg_dir, filename, precision)
	Constructor from components, passing the properties of time_based_controllers.

procedure, pass(this)	free (this)
	Destructor.

procedure, pass(this)	compute_ (this, time)
	Compute the means.

procedure, pass(this)	restart_ (this, time)

procedure, pass(this)	init_base (this, json, case)
	Constructor for the simulation_component_t (base) class.

generic	init_base_from_components (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from components.

generic	init_base_from_components (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from components.

procedure, pass(this)	init_base_from_controllers (this, case, order, preprocess_controller, compute_controller, output_controller)
	Constructor for the simulation_component_t (base) class from time_based_controllers, essentially directly from all components (we reserve the `_from_components` name for the generic binding).

procedure, pass(this)	init_base_from_controllers_properties (this, case, order, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	Constructor for the simulation_component_t (base) class from properties of time_based_controllers, so the latter are constructed instead of assigned.

procedure, pass(this)	free_base (this)
	Destructor for the simulation_component_t (base) class.

procedure, pass(this)	restart (this, time)
	Wrapper for calling `set_counter` for the time based controllers. Serves as the public interface.

procedure, pass(this)	preprocess (this, time)
	Wrapper for calling `preprocess_` based on the `preprocess_controller`. Serves as the public interface.

procedure, pass(this)	compute (this, time)
	Wrapper for calling `compute_` based on the `compute_controller`. Serves as the public interface.

procedure(simulation_component_init), deferred, pass	init (this, json, case)
	The common constructor using a JSON dictionary.

procedure(simulation_component_free), deferred, pass	free (this)
	Destructor.

procedure, pass(this)	preprocess_ (this, time)
	The preprocessing function to be executed during the run.

procedure, pass(this)	compute_ (this, time)
	The main function to be executed during the run.

procedure, pass(this)	restart_ (this, time)
	The restart function to be called upon restarting simulation.

procedure, pass(this)	parse_json (this, json, case_params, preprocess_control, preprocess_value, compute_control, compute_value, output_control, output_value)
	JSON parameter parser for the time-based controllers.

Public Attributes
real(kind=rp)	start_time
	When to start averaging.

real(kind=rp)	time
	Current time. Uses to compute time delta since last run of compute.

type(mean_field_t), dimension(:), allocatable	mean_fields
	The averaged fields.

integer	n_avg_fields = 0
	Number of fields to average.

character(len=20), dimension(:), allocatable	field_names
	The names of the fields to average.

type(case_t), pointer	case
	Pointer to the simulation case.

type(time_based_controller_t)	preprocess_controller
	Controller for when to run `preprocess`.

type(time_based_controller_t)	compute_controller
	Controller for when to run `compute`.

type(time_based_controller_t)	output_controller
	Controller for when to do output.

integer	order
	The execution order, lowest excutes first.

Private Member Functions
procedure, pass(this), private	init_common (this, start_time, coef, avg_dir, filename, precision)
	Common part of both constructors.

Private Attributes
type(mean_field_output_t), private	output
	Output writer.

Detailed Description

Definition at line 53 of file user_stats.f90.

Member Function/Subroutine Documentation

◆ compute()

procedure, pass(this) simulation_component::simulation_component_t::compute	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 88 of file simulation_component.f90.

◆ compute_() [1/2]

procedure, pass(this) simulation_component::simulation_component_t::compute_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 96 of file simulation_component.f90.

◆ compute_() [2/2]

procedure, pass(this) user_stats::user_stats_t::compute_	(	class(user_stats_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Parameters

time	The current time state.

Definition at line 86 of file user_stats.f90.

◆ free() [1/2]

procedure(simulation_component_free), deferred, pass simulation_component::simulation_component_t::free ( class(simulation_component_t), intent(inout) this )

pure virtualinherited

Definition at line 92 of file simulation_component.f90.

◆ free() [2/2]

procedure, pass(this) user_stats::user_stats_t::free ( class(user_stats_t), intent(inout) this )

Definition at line 84 of file user_stats.f90.

◆ free_base()

procedure, pass(this) simulation_component::simulation_component_t::free_base ( class(simulation_component_t), intent(inout) this )

inherited

Definition at line 78 of file simulation_component.f90.

◆ init() [1/2]

procedure(simulation_component_init), deferred, pass simulation_component::simulation_component_t::init	(	class(simulation_component_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

pure virtualinherited

Definition at line 90 of file simulation_component.f90.

◆ init() [2/2]

procedure, pass(this) user_stats::user_stats_t::init	(	class(user_stats_t), intent(inout), target	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

Parameters

json	The json paramter dictionary.
case	The neko case object.

Definition at line 70 of file user_stats.f90.

◆ init_base()

procedure, pass(this) simulation_component::simulation_component_t::init_base	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		class(case_t), intent(inout), target	case
	)

inherited

Definition at line 62 of file simulation_component.f90.

◆ init_base_from_components() [1/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 64 of file simulation_component.f90.

◆ init_base_from_components() [2/2]

generic simulation_component::simulation_component_t::init_base_from_components	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 64 of file simulation_component.f90.

◆ init_base_from_controllers()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.

Definition at line 70 of file simulation_component.f90.

◆ init_base_from_controllers_properties()

procedure, pass(this) simulation_component::simulation_component_t::init_base_from_controllers_properties	(	class(simulation_component_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value
	)

inherited

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.

Definition at line 75 of file simulation_component.f90.

◆ init_common()

procedure, pass(this), private user_stats::user_stats_t::init_common	(	class(user_stats_t), intent(inout)	this,
		real(kind=rp), intent(in)	start_time,
		type(coef_t), intent(inout)	coef,
		character(len=*), intent(in)	avg_dir,
		character(len=*), intent(in)	filename,
		integer, intent(in), optional	precision
	)

private

Parameters

start_time	The start time for gathering samples for the average.
coef	The SEM coefficients.
avg_dir	The averaging direction.

Definition at line 82 of file user_stats.f90.

◆ init_from_components() [1/2]

generic user_stats::user_stats_t::init_from_components	(	class(user_stats_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		real(kind=rp), intent(in)	start_time,
		type(coef_t), intent(inout)	coef,
		character(len=*), intent(in)	avg_dir,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
start_time	The start time for gathering samples for the average.
coef	The SEM coefficients.
avg_dir	The averaging direction.
filename	The name of the file save the fields to. Optional, if not provided, fields are added to the main output file.
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 72 of file user_stats.f90.

◆ init_from_components() [2/2]

generic user_stats::user_stats_t::init_from_components	(	class(user_stats_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		real(kind=rp), intent(in)	start_time,
		type(coef_t), intent(inout)	coef,
		character(len=*), intent(in)	avg_dir,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
start_time	The start time for gathering samples for the average.
coef	The SEM coefficients.
avg_dir	The averaging direction.
filename	The name of the file save the fields to. Optional, if not
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 72 of file user_stats.f90.

◆ init_from_controllers()

procedure, pass(this) user_stats::user_stats_t::init_from_controllers	(	class(user_stats_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		type(time_based_controller_t), intent(in)	preprocess_controller,
		type(time_based_controller_t), intent(in)	compute_controller,
		type(time_based_controller_t), intent(in)	output_controller,
		real(kind=rp), intent(in)	start_time,
		type(coef_t), intent(inout)	coef,
		character(len=*), intent(in)	avg_dir,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	The controller for running preprocessing.
compute_controller	The controller for running compute.
output_controller	The controller for producing output.
start_time	The start time for gathering samples for the average.
coef	The SEM coefficients.
avg_dir	The averaging direction.
filename	The name of the file save the fields to. Optional, if not
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 75 of file user_stats.f90.

◆ init_from_controllers_properties()

procedure, pass(this) user_stats::user_stats_t::init_from_controllers_properties	(	class(user_stats_t), intent(inout)	this,
		class(case_t), intent(inout), target	case,
		integer	order,
		character(len=*), intent(in)	preprocess_control,
		real(kind=rp), intent(in)	preprocess_value,
		character(len=*), intent(in)	compute_control,
		real(kind=rp), intent(in)	compute_value,
		character(len=*), intent(in)	output_control,
		real(kind=rp), intent(in)	output_value,
		real(kind=rp), intent(in)	start_time,
		type(coef_t), intent(inout)	coef,
		character(len=*), intent(in)	avg_dir,
		character(len=*), intent(in), optional	filename,
		integer, intent(in), optional	precision
	)

Parameters

case	The simulation case object.
order	The execution oder priority of the simcomp.
preprocess_controller	Control mode for preprocessing.
preprocess_value	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_value	Value parameter for computing.
output_controller	Control mode for output.
output_value	Value parameter for output.
start_time	The start time for gathering samples for the average.
coef	The SEM coefficients.
avg_dir	The averaging direction.
filename	The name of the file save the fields to. Optional, if not provided, fields are added to the main output file.
precision	The real precision of the output data. Optional, defaults to single precision.

Definition at line 79 of file user_stats.f90.

◆ parse_json()

procedure, pass(this) simulation_component::simulation_component_t::parse_json	(	class(simulation_component_t), intent(inout)	this,
		type(json_file), intent(inout)	json,
		type(json_file), intent(inout)	case_params,
		character(len=:), intent(inout), allocatable	preprocess_control,
		real(kind=rp), intent(out)	preprocess_value,
		character(len=:), intent(inout), allocatable	compute_control,
		real(kind=rp), intent(out)	compute_value,
		character(len=:), intent(inout), allocatable	output_control,
		real(kind=rp), intent(out)	output_value
	)

inherited

Parameters

json	The JSON dictionary of the simcomp.
case_params	The entire case configuration JSON.
preprocess_value	Control mode for preprocessing.
preprocess_controller	Value parameter for preprocessing.
compute_controller	Control mode for computing.
compute_controller	Value parameter for computing.
output_controller	Control mode for output.
output_controller	Value parameter for output.

Definition at line 100 of file simulation_component.f90.

◆ preprocess()

procedure, pass(this) simulation_component::simulation_component_t::preprocess	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 84 of file simulation_component.f90.

◆ preprocess_()

procedure, pass(this) simulation_component::simulation_component_t::preprocess_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 94 of file simulation_component.f90.

◆ restart()

procedure, pass(this) simulation_component::simulation_component_t::restart	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 81 of file simulation_component.f90.

◆ restart_() [1/2]

procedure, pass(this) simulation_component::simulation_component_t::restart_	(	class(simulation_component_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

inherited

Parameters

time	The current time.

Definition at line 98 of file simulation_component.f90.

◆ restart_() [2/2]

procedure, pass(this) user_stats::user_stats_t::restart_	(	class(user_stats_t), intent(inout)	this,
		type(time_state_t), intent(in)	time
	)

Definition at line 87 of file user_stats.f90.

Member Data Documentation

◆ case

type(case_t), pointer simulation_component::simulation_component_t::case

inherited

Definition at line 51 of file simulation_component.f90.

◆ compute_controller

type(time_based_controller_t) simulation_component::simulation_component_t::compute_controller

inherited

Definition at line 55 of file simulation_component.f90.

◆ field_names

character(len=20), dimension(:), allocatable user_stats::user_stats_t::field_names

Definition at line 64 of file user_stats.f90.

◆ mean_fields

type(mean_field_t), dimension(:), allocatable user_stats::user_stats_t::mean_fields

Definition at line 60 of file user_stats.f90.

◆ n_avg_fields

integer user_stats::user_stats_t::n_avg_fields = 0

Definition at line 62 of file user_stats.f90.

◆ order

integer simulation_component::simulation_component_t::order

inherited

Definition at line 59 of file simulation_component.f90.

◆ output

type(mean_field_output_t), private user_stats::user_stats_t::output

private

Definition at line 66 of file user_stats.f90.

◆ output_controller

type(time_based_controller_t) simulation_component::simulation_component_t::output_controller

inherited

Definition at line 57 of file simulation_component.f90.

◆ preprocess_controller

type(time_based_controller_t) simulation_component::simulation_component_t::preprocess_controller

inherited

Definition at line 53 of file simulation_component.f90.

◆ start_time

real(kind=rp) user_stats::user_stats_t::start_time

Definition at line 56 of file user_stats.f90.

◆ time

real(kind=rp) user_stats::user_stats_t::time

Definition at line 58 of file user_stats.f90.

The documentation for this type was generated from the following file:

/home/runner/work/neko/neko/src/simulation_components/user_stats.f90

Public Member Functions

Public Attributes

Private Member Functions

Private Attributes

Detailed Description

Member Function/Subroutine Documentation

◆ compute()

◆ compute_() [1/2]

◆ compute_() [2/2]

◆ free() [1/2]

◆ free() [2/2]

◆ free_base()

◆ init() [1/2]

◆ init() [2/2]

◆ init_base()

◆ init_base_from_components() [1/2]

◆ init_base_from_components() [2/2]

◆ init_base_from_controllers()

◆ init_base_from_controllers_properties()

◆ init_common()

◆ init_from_components() [1/2]

◆ init_from_components() [2/2]

◆ init_from_controllers()

◆ init_from_controllers_properties()

◆ parse_json()

◆ preprocess()

◆ preprocess_()

◆ restart()

◆ restart_() [1/2]

◆ restart_() [2/2]

Member Data Documentation

◆ case

◆ compute_controller

◆ field_names

◆ mean_fields

◆ n_avg_fields

◆ order

◆ output

◆ output_controller

◆ preprocess_controller

◆ start_time

◆ time
